Subaddress Register
0x03 Output
Control
0x04 Extended
Output
Control
Downloaded from Elcodis.com electronic components distributor
Bit Description
SD_DUP_AV. Duplicates the AV
codes from the Luma into the
chroma path.
Reserved.
OF_SEL[3:0]. Allows the user to
choose from a set of output formats.
TOD. Three-state output drivers.
This bit allows the user to three-
state the output drivers: P[19:0], HS,
VS, FIELD, and SFL.
VBI_EN. Allows VBI data (Lines 1 to
21) to be passed through with only
a minimum amount of filtering
performed.
RANGE. Allows the user to select the
range of output values. Can be
BT656-compliant, or can fill the
whole accessible number range.
EN_SFL_PIN.
BL_C_VBI. Blank chroma during VBI.
If set, enables data in the VBI region
to be passed through the decoder
undistorted.
TIM_OE. Timing signals output
enable.
Reserved.
Reserved.
BT656-4. Allows the user to select an
output mode compatible with
ITU- R BT656-3/4.
Bits
7 6 5 4 3 2 1 0
0
1
0
0 0 0 0
0 0 0 1
0 0 1 0
0 0 1 1
0 1 0 0
0 1 0 1
0 1 1 0
0 1 1 1
1 0 0 0
1 0 0 1
1 0 1 0
1 0 1 1
1 1 0 0
1 1 0 1
1 1 1 0
1 1 1 1
0
1
0
1
0
1
0
1
0
1
0
1
x x
1
0
1
Rev. B | Page 73 of 100
ADV7181B
Comments Notes
AV codes to suit 8-bit
interleaved data output
AV codes duplicated (for
16-bit interfaces)
Set as default
Reserved
Reserved
16-bit @ LLC1 4:2:2
8-bit @ LLC1 4:2:2
ITU-R BT.656
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Output pins enabled See TIM_OE,
Address 0x04[3] and
TRI_LLC, Address
0x1D[7]
Drivers three-stated
All lines filtered and scaled
Only active video region
filtered
16 < Y < 235, 16 < C < 240 ITU-R BT.656.
1 < Y < 254, 1 < C < 254 Extended range.
SFL output is disabled SFL output enables
encoder and
SFL information output on
decoder to be
the SFL pin
connected directly.
Decode and output color During VBI.
Blank Cr and Cb
HS, VS, F three-stated Controlled by TOD.
HS, VS, F forced active
BT656-3-compatible
BT656-4-compatible
