Mode 4 CVBS Tuner Input CVBS PAL on AIN6
All standards are supported through autodetect, 8-bit, ITU-R BT.656 output on P15 to P8.
Table 89. Mode 4 Tuner Input CVBS PAL Only
Register Address
0x00
0x07
0x15
0x17
0x19
0x1D
0x0F
0x3A
0x3D
0x3F
0x50
0xC3
0xC4
0x0E
0x50
0x52
0x58
0x77
0x7C
0x7D
0x90
0x91
0x92
0x93
0x94
0xCF
0xD0
0xD6
0xE5
0xD5
0xD7
0xE4
0xE9
0xEA
0x0E
Downloaded from Elcodis.com electronic components distributor
Register Value Notes
0x80 Force PAL input only mode.
0x01 Enable PAL autodetection only.
0x00 Slow down digital clamps.
0x41 Set CSFM to SH1.
0xFA Stronger dot crawl reduction.
0x40 Enable 28 MHz crystal.
0x40 TRAQ.
0x16 Power down ADC 1 and ADC 2.
0xC3 MWE enable manual window.
0xE4 BGB to 36.
0x0A Set higher DNR threshold.
0x05 Manual mux AIN6 to ADC0 (0101).
0x80 Enable manual muxing.
0x80 ADI recommended programming sequence. This sequence must be followed exactly when
setting up the decoder.
0x20 Recommended setting.
0x18 Recommended setting.
0xED Recommended setting.
0xC5 Recommended setting.
0x93 Recommended setting.
0x00 Recommended setting.
0xC9 Recommended setting.
0x40 Recommended setting.
0x3C Recommended setting.
0xCA Recommended setting.
0xD5 Recommended setting.
0x50 Recommended setting.
0x4E Recommended setting.
0xDD Recommended setting.
0x51 Recommended setting.
0xA0 Recommended setting.
0xEA Recommended setting.
0x3E Recommended setting.
0x3E Recommended setting.
0x0F Recommended setting.
0x00 Recommended setting.
Rev. B | Page 91 of 100
