Register Name
Reserved
Resample Control
Reserved
Gemstar Ctrl 1
Gemstar Ctrl 2
Gemstar Ctrl 3
Gemstar Ctrl 4
GemStar Ctrl 5
CTI DNR Ctrl 1
CTI DNR Ctrl 2
Reserved
CTI DNR Ctrl 4
Lock Count
Reserved
Free-Run Line Length 1
Reserved
VBI Info
WSS 1
WSS 2
EDTV 1
EDTV 2
EDTV 3
CGMS 1
CGMS 2
CGMS 3
CCAP 1
CCAP 2
Letterbox 1
Letterbox 2
Letterbox 3
Reserved
CRC Enable
Reserved
ADC Switch 1
ADC Switch 2
Reserved
Letterbox Control 1
Letterbox Control 2
Reserved
Reserved
Reserved
SD Offset Cb
SD Offset Cr
SD Saturation Cb
SD Saturation Cr
NTSC V Bit Begin
NTSC V Bit End
NTSC F Bit Toggle
PAL V Bit Begin
PAL V Bit End
PAL F Bit Toggle
Reserved
Downloaded from Elcodis.com electronic components distributor
Reset Value rw
xxxx xxxx rw
0100 0001 rw
xxxx xxxx rw
00000000 rw
0000 0000 rw
0000 0000 rw
0000 0000 rw
xxxx xxx0 rw
1110 1111 rw
0000 1000 rw
xxxx xxxx rw
0000 1000 rw
0010 0100 rw
xxxx xxxx rw
0000 0000 w
0000 0000 w
xxxx xxxx r
xxxx xxxx r
xxxx xxxx r
xxxx xxxx r
xxxx xxxx r
xxxx xxxx r
xxxx xxxx r
xxxx xxxx r
xxxx xxxx r
xxxx xxxx r
xxxx xxxx r
xxxx xxxx r
xxxx xxxx r
xxxx xxxx r
xxxx xxxx rw
0001 1100 w
xxxx xxxx rw
xxxx xxxx rw
0xxx xxxx rw
xxxx xxxx rw
1010 1100 rw
0100 1100 rw
0000 0000 rw
0000 0000 rw
0001 0100 rw
1000 0000 rw
1000 0000 rw
1000 0000 rw
1000 0000 rw
0010 0101 rw
0000 0100 rw
0110 0011 rw
0110 0101 rw
0001 0100 rw
0110 0011 rw
xxxx xxxx rw
Rev. B | Page 63 of 100
ADV7181B
Subaddress
Dec Hex
62 to 64 0x3E to 0x40
65 0x41
66 to 71 0x42 to 0x47
72 0x48
73 0x49
74 0x4A
75 0x4B
76 0x4C
77 0x4D
78 0x4E
79 0x4F
80 0x50
81 0x51
82 to142 0x52 to 0x8E
143 0x8F
144 0x90
144 0x90
145 0x91
146 0x92
147 0x93
148 0x94
149 0x95
150 0x96
151 0x97
152 0x98
153 0x99
154 0x9A
155 0x9B
156 0x9C
157 0x9D
158 to 177 0x9E to 0xB1
178 0xB2
179 to 194 0xB2 to 0xC2
195 0xC3
196 0xC4
197 to 219 0xC5 to 0xDB
220 0xDC
221 0xDD
222 0xDE
223 0xDF
224 0xE0
225 0xE1
226 0xE2
227 0xE3
228 0xE4
229 0xE5
230 0xE6
231 0xE7
232 0xE8
233 0xE9
234 0xEA
235 to 243 0xEB to 0xF3
