Operating Guide | VLT® AQUA Drive FC 202
Table 49: Fuse Options
Input voltage (V)
380–480
380–480
525–690
The fuses listed in table 49 are suitable for use on a circuit capable of delivering 100000 A
voltage rating. With the proper fusing, the drive short-circuit current rating (SCCR) is 100000 A
internal drive fusing to meet the 100 kA SCCR. E3h and E4h drives must be fitted with Type aR fuses to meet the 100 kA SCCR.
DISCONNECT SWITCH SCCR REQUIREMENTS
All units ordered and supplied with a factory-installed disconnect switch require Class L branch circuit fusing to meet the 100
kA SCCR for the drive.
If a circuit breaker is used, the SCCR rating is 42 kA. The input voltage and power rating of the drive determines the specific
-
Class L fuse. The input voltage and power rating are found on the product nameplate.
Table 50: Disconnect Switch SCCR Requirements
Input voltage (V)
380–480
380–480
525–690
525–690
142 | Danfoss A/S © 2020.01
Model
N355–N400
N450–N560
All
N O T I C E
Model Short circuit rating (A)
N355–N450 42000
100000
N500–N560 42000
100000
N450–N630 42000
100000
N710–N800 42000
100000
Bussmann part number
170M6014
170M7309
170M7342
(symmetrical), depending on the drive
rms
. E1h and E2h drives are supplied with
rms
Required protection
Circuit breaker
Class L fuse, 800 A
Circuit breaker
Class L fuse, 1200 A
Circuit breaker
Class L fuse, 800 A
Circuit breaker
Class L fuse, 1200 A
AQ275652274277en-000101 / 130R0708
Specifications
