Operating Guide | VLT® AQUA Drive FC 202
11 Output contactor, and so on
13 Common ground busbar. Follow local and national
requirements for cabinet grounding.
15 Metal box
17 Motor
Illustration 17:
Example of Proper EMC Installation
Danfoss A/S © 2020.01
12 Cable insulation stripped
14 Brake resistor
16 Connection to motor
18 EMC cable gland
AQ275652274277en-000101 / 130R0708| 39
Electrical Installation
