Technical Manual
Push-button 55 / Plus 55 [BE-TA55xx.x2]

4.5.1.1 Settings Logic 1-4

If a logic is activated, the following settings are possible:
ETS Text
Function/Object
description
Additional text
Object type
■
■
■
■
Value /
Scene number
Sending condition
■
■
■
■
■
Output inverted
■
■
Table 40: Settings – Logic 1-4
MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Phone +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
Dynamic range
[Default value]
free text
[up to 40 bytes allowed].
free text
[up to 40 bytes allowed].
1 Bit DPT 1.001 Switch
1 Byte DPT 17.001 Scene number
1 Byte DPT 5.005 Decimal value
(0...255)
2 Bit DPT 2.001 Switch control
any value according to DPT
not automatic
on input telegram
on change of output
on change of output (send only "0")
on change of output (send only "1")
not active
active
Comment
Text input for describing the logic
function and its objects.
Text input for additional information.
Setting the object type for the logic
output.
Setting of the value which is to be
sent when the logic operation is
fulfilled.
Only for object types "Scene",
"Decimal value", "Switch control".
Setting the sending condition for the
output object.
Only for object type "Switch".
Setting whether the output signal is
to be inverted.
Only for object type "Switch".
