Push-button 55 / Plus 55 [BE-TA55xx.x2]
The following table shows the available communications objects:
Number Name / Object function
0 PB1/2: –
Percent value, Decimal value
3 PB1/2: – Status Percent value,
Status Decimal value
Table 19: Communication objects – Send Values - Subfunction: Shift Values
MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Phone +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
Length Usage
1 Byte Sending of the value to be shifted.
DPT depending on the parameter setting
1 Byte Receiving of the status value.
DPT depending on the parameter setting
