Technical Manual
Push-button 55 / Plus 55 [BE-TA55xx.x2]
4.5 Logic
(only Push-button Plus 55)
The button has 4 individually activatable and individually programmable logic modules.

4.5.1 Logic basic settings

The following table shows all available settings:
ETS Text
Setting logic 1-4
Behaviour on bus power
return
Table 39: Settings – Logic basic settings
The logic setting can be used to select either a logical operation (AND / OR) or, with "send value on button
activation", a special function for sending a second value for a pressed button (Description follows under
4.5.2 Submenu - Logic 1-4
Further parameters are then displayed for an activated logic.
MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Phone +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
Dynamic range
[Default value]
not active
■
AND
■
OR
■
send value on button activation
■
do not request external logic
■
objects
request external logic objects
■
)
Comment
Activating the logic function and setting
the logical operation
Setting whether the objects are to be
actively requested after a reset.
42 / 49
