Technical Manual
Push-button 55 / Plus 55 [BE-TA55xx.x2]

4.2 Button functions - General

The table shows the available settings:
ETS Text
Buttons 1/2 (top left / right)
Buttons 3/4 (2. line left / right)
Buttons 5/6 (3. line left / right)
Buttons 7/8 (bottom left / right)
Reaction time on keypress
Time for long keypress
(Basic setting)
Table 7: Settings – Button functions
It is determined in advance how a pair of buttons is to be activated and used.
With the "single-button function", only one button is used for one function.
With the " two-button function", 2 buttons are always used for one function and the operating concept
works like a rocker. It is possible to specify for each button which value (on/off, up/down, brighter/darker,
etc.) it is to send.
A corresponding time can be set via "Time for long keypress (basic setting)".
Note: This time is the basic setting for all buttons.
MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Phone +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
Dynamic range
[Default value]
not active
■
single-button function
■
two-button function
■
fast
■
medium
■
slow
■
0,1 s – 30,0 s
[0,4 s]
Comment
Setting the functions for the respective
button pair
Setting the reaction time or debounce
time for the buttons.
Setting from when a long keypress is
detected.
