MDT Push Button 55 Technical Manual page 23

Technical Manual
Push-button 55 / Plus 55 [BE-TA55xx.x2]
ETS Text
Group extra long sends
Time for long keypress
Time for extra long
keypress
Special function: Additional object
Datapoint type
(2. object)
Left/Right button:
Value/Scene number
Value/Scene number
Table 14: Settings – Send values - Subfunction: Send values
Note: For details on the Innovative group control, see
When selecting "additional object", another communication object appears. It is possible here to send
different values to two separate objects when pressing a button. For example, a dimming value in "%" can
be sent to a dimming actuator with the first object and at the same time an "RGB value" to an LED
controller.
MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Phone +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
Dynamic range
[Default value]
value for left and right button
■
only value for left button
■
only value for right button
■
Basic setting
0,1 s – 30,0 s
0,1 s – 30,0 s
[2,0 s]
1 Bit DPT 1.001 Switch
■
2 Bit DPT 2.001 Switch Control
■
1 Byte DPT 5.001 Percent
■
(0...100%)
1 Byte DPT 5.005 Decimal factor
■
(0...255)
1 Byte DPT 17.001 Scene number
■
2 Byte DPT 7.600
■
Colour temperature (Kelvin)
2 Byte DPT 9.001 Temperature (°C)
■
2 Byte DPT 9.004 Brightness (Lux)
■
3 Byte DPT 232.600
■
RGB Value 3x (0...255)
any value according to set datapoint
type
any value according to set datapoint
type
Comment
Only with two-button
Setting, which button is to send
when the button is pressed extra
long.
Setting of an individual time from
when a long keystroke is detected.
Setting of an individual time from
when a extra long keystroke is
detected.
Setting the type of datapoint to be
sent.
Only with two-button function.
Setting the values to be sent to the
2nd object.
Only with single button function.
Setting the value to be sent to the
2nd object.
4.3.2 Switch (General)
23 / 49
function.
