MDT Push Button 55 Technical Manual page 13

Technical Manual
Push-button 55 / Plus 55 [BE-TA55xx.x2]
No. Name
* 20/40/60/80 Logic 1:
* 21/41/61/81 Logic 1:
* 22/42/62/82 Logic 1:
* 22/42/62/82 Logic 1:
* 22/42/62/82 Logic 1:
* 22/42/62/82 Logic 1:
+ 3 next Logic
Table 2: Communication objects – Standard settings: Logic
* Logic objects always come after the buttons in the object list. This means that the object numbers are
dependent on the device version.
2-fold Push-button from object no. 20
4-fold Push-button from object no. 40
6-fold Push-button from object no. 60
8-fold Push-button from object no. 80
No. Name
* 32/52/72/92 LED 1
+ 1 next LED
* 40/60/80/100 LED 1 Priority
+ 1 next LED Priority
* 48/68/88/108 All LEDs
Table 3: Communication objects – Standard settings: Status LED
* Objects for Status LEDs always come after the buttons in the object list. This means that the object
numbers are dependent on the device version.
2-fold Push-button from object no. 32
4-fold Push-button from object no. 52
6-fold Push-button from object no. 72
8-fold Push-button from object no. 92
MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Phone +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
Standard Settings – Logic
Object Function
Input A
Input B
Output: Switch
Output: Value
Output: Value
Output: Scene
Standard Settings – Status LED
Object Function
Switch
Switch
Lock object
Length C R W T
1 Bit
■ ■ ■
1 Bit
■ ■ ■
1 Bit
■ ■ ■
2 Bit
■ ■ ■
1 Byte
■ ■ ■
1 Byte
■ ■ ■
Length C R W T
1 Bit
■ ■ ■
1 Bit
■ ■ ■
1 Bit
■ ■ ■
13 / 49
U
■
■
U
■
■
■
