Technical Manual
Push-button 55 / Plus 55 [BE-TA55xx.x2]

4 ETS Parameter

4.1 General Settings

The following table shows the available settings:
ETS Text
Startup time
Send „In operation" cyclically
Objects „Status for toggle"
after bus power return
Table 5: General settings
Startup time
This time defines when the unit "boots up" after a restart (reset, reprogramming, bus voltage recovery).
This can be important if - example 1 - a bus reset is carried out. If there are many units on a line, all units
would start at the same time and load the bus. With a variable time, the units can thus start differently.
„In operation"
"In operation" is used to show on the bus that the unit is "alive". If activated, an ON telegram is sent
cyclically.
The table shows the general communication objects:
Number Name / Object function
* 54/74/94/114 In operation – Output
Table 6: General communication objects
* Numbers apply to devices with 2/4/6/8 buttons.
MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Phone +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
Dynamic range
[Default value]
2 ... 240 s
[2 s]
not active
1 min – 24 h
do not request
■
request
■
Length
1 Bit
Comment
Sets the time between restart and
functional start-up of the device.
Activation of a cyclical "In operation"
telegram.
Setting whether the objects "Status for
toggle" are to be automatically queried
on bus voltage recovery.
Usage
Sending a cyclic "In operation" telegram
15 / 49
