Push-button 55 / Plus 55 [BE-TA55xx.x2]
Parameter "Switching type" (only available with two-button function)
Limit stop: With the switching type limit stop, the 4th toggle value is sent again after sending the 4th
toggle value.
Overrun: With the overrun switching type, the 1st toggle value is sent again after the 4th toggle value.
Note: For the single button function, this parameter is permanently set to "overrun".
The following table shows the available communication objects:
Number Name / Object function
0 PB1:
PB1/2: –
Forcible control, Percent value...
1 PB1:
PB1/2: –
Status: Percent value...
2 PB1 long:
PB1/2 long – Switch
Table 17: Communication objects – Send Values - Toggle values/scenes (up to 4 values)
MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Phone +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
Length Usage
Transmission of the toggle value.
DPT depending on the parameter setting
Receiving of the status.
DPT depending on the parameter setting.
Status for RGB value, Forcible control and
Scene number not available
1 Bit Switch function of the long button.
Only appears with the setting "ON or OFF
to second object".t
