Push-button 55 / Plus 55 [BE-TA55xx.x2]
ETS Text
Group extra long sends
Time for long keypress
Time for extra long keypress
Table 9: Settings – Switch
With the "Innovative group control", it is possible to send to up to three different group addresses by
touching/pressing a button for a longer time. The time for the long and the extra-long keystroke is set
individually.
With the single-button function, the value defined in the sub-function is always sent for the long and the
extra-long group.
With the two-button function, the transmission behaviour for the long and the extra-long group can be set
individually.
Note:
All groups are always sent one after the other.
Example:
Time long key press:
Time extra long key press: 4 s
If the key is now pressed for at least 4 seconds, the first value is transmitted immediately, after 2 seconds
the value for "group long" and after 4 seconds the value for "group extra long".
.
MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Phone +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
Dynamic range
[Default value]
ON and OFF
■
only ON
■
only OFF
■
Basic setting
0,1 s – 30,0 s
0,1 s – 30,0 s
[2,0 s]
2 s
Comment
Only for two-button function, when
„Group long keypress" and "Group
extra long keypress" are active.
Defines the sending behaviour when
a long keypress is active.
For single-button functions, the
sending behaviour is defined
according to the subfunction.
Setting from when a long keypress is
detected. Basic setting refers to the
time at menu "Button functions".
Setting from when an extra long
keypress is detected
