MDT Push Button 55 Technical Manual page 36

Technical Manual
Push-button 55 / Plus 55 [BE-TA55xx.x2]
The following table shows the available communication objects:
Number Name / Object function
0 PB1:
PB1/2: – Blinds Up/Down
0 PB1/2 short: –
Shutter Up/Down/Stop
1 PB1:
PB1/2: –
Stop / Slats Open/Close
1 PB1/2 long: –
Central Shutter Up/Down/Stop
2 PB1: –
Status for change of direction
3 PB1 Group extra long:
PB1/2 Group extra long: –
Blinds Up/Down
4 PB1 Group extra long:
PB1/2 Group extra long: –
Stop / Slats Open/Close
Table 29: Communication objects – Blinds/Shutter
MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Phone +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
Length Usage
1 Bit Up/down command for the shutter actuator
1 Bit MDT Single Object Control.
Up/Down/Stop function.
Only with two-button function and for
roller shutters!
1 Bit Open/close slats and stop command.
1 Bit MDT Single Object Control.
Central object for up/down/stop function.
Only with two-button function and for
roller shutters!
1 Bit Only with single-button function.
Receipt of the status with current
information about the direction of the
shutter actuator
1 Bit Up/down command for the shutter actuator
1 Bit Slat control with open/close and stop
command
36 / 49
