Technical Manual
Push-button 55 / Plus 55 [BE-TA55xx.x2]
No. Name
* 49/69/89/109 LED Orientation light
* 54/74/94/114 In operation
Table 4: Communication objects – Standard settings: General objects
* General objects are at the end of the object list. This means that the numbers depend on the number of
buttons.
2-fold Push-button from object no. 49
4-fold Push-button from object no. 69
6-fold Push-button from object no. 89
8-fold Push-button from object no. 109
The table above shows the preset default settings. The priority of the individual communications objects
and the flags can be adjusted by the user as required. The flags assign the communication objects their
respective tasks in programming, where C stands for communication, R for read, W for write, T for transmit
and U for update.
MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Phone +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
Standard Settings – General objects
Object Function
Switch
Output
Length C R W T
1 Bit
■ ■
1 Bit
■ ■ ■
14 / 49
U
