Technical Manual

Push-button 55 / Plus 55 [BE-TA55xx.x2]

4.4.1.2 Lock object for LEDs

Unlike the lock objects for the buttons, there is only one lock object for the LEDs, which affects all LEDs

(except the LED orientation light!). If the LED lock object is controlled with a logical "1", all LEDs are locked

and can therefore no longer be controlled. LEDs that were previously controlled are switched-off. With a

logical "0", the lock is removed and control is possible again. Previous switching states are restored.

The following table shows the available communication objects:

Number

Name / Object function

* 48/68/88/108

All LEDs – Lock object

Table 35: Communication objects – Lock object for LEDs

* Object numbers depend on the device version (number of buttons).

MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany

Phone +49 (0) 2263 880 · knx@mdt.de · www.mdt.de

Length

Usage

1 Bit

Locking all LEDs

39 / 49
