MDT Push Button 55 Technical Manual page 24

Technical Manual
Push-button 55 / Plus 55 [BE-TA55xx.x2]
The following table shows the available communication objects:
Number Name / Object function
0 PB1:
PB1/2: –
Forcible control, Percent value ...
2 PB1: (2. object)
PB1/2: (2. object) –
Forcible control, Percent value...
2 PB1 Group long:
PB1/2 Group long –
Forcible control, Percent value...
4 PB1 Group extra long:
PB1/2 Group extra long: –
Forcible control, Percent value...
Table 15: Communication objects – Send values - Subfunction: Send values
MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Phone +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
Length Usage
Switch function of the button(s).
DPT depending on the parameter setting
Switch function of the button(s) on the
second object.
DPT depending on the parameter setting
Switch function with long keystroke.
DPT depending on the parameter setting.
Switch function with extra long keystroke.
DPT depending on the parameter setting
24 / 49
