DDR3 Pin Assignment:
Signal Name
DDR3_DQS0_P
DDR3_DQS0_N
DDR3_DQS1_P
DDR3_DQS1_N
DDR3_DQS2_P
DDR3_DQS2_N
DDR3_DQS3_P
DDR3_DQS4_N
DDR3_DQ[0]
DDR3_DQ [1]
DDR3_DQ [2]
DDR3_DQ [3]
DDR3_DQ [4]
DDR3_DQ [5]
DDR3_DQ [6]
DDR3_DQ [7]
DDR3_DQ [8]
DDR3_DQ [9]
DDR3_DQ [10]
DDR3_DQ [11]
DDR3_DQ [12]
DDR3_DQ [13]
DDR3_DQ [14]
DDR3_DQ [15]
DDR3_DQ [16]
DDR3_DQ [17]
DDR3_DQ [18]
DDR3_DQ [19]
DDR3_DQ [20]
DDR3_DQ [21]
DDR3_DQ [22]
DDR3_DQ [23]
DDR3_DQ [24]
DDR3_DQ [25]
www.alinx.com
AC7010C / AC7020C User Manual
ZYNQ Pin Name
PS_DDR_DQS_P0_502
PS_DDR_DQS_N0_502
PS_DDR_DQS_P1_502
PS_DDR_DQS_N1_502
PS_DDR_DQS_P2_502
PS_DDR_DQS_N2_502
PS_DDR_DQS_P3_502
PS_DDR_DQS_N3_502
PS_DDR_DQ0_502
PS_DDR_DQ1_502
PS_DDR_DQ2_502
PS_DDR_DQ3_502
PS_DDR_DQ4_502
PS_DDR_DQ5_502
PS_DDR_DQ6_502
PS_DDR_DQ7_502
PS_DDR_DQ8_502
PS_DDR_DQ9_502
PS_DDR_DQ10_502
PS_DDR_DQ11_502
PS_DDR_DQ12_502
PS_DDR_DQ13_502
PS_DDR_DQ14_502
PS_DDR_DQ15_502
PS_DDR_DQ16_502
PS_DDR_DQ17_502
PS_DDR_DQ18_502
PS_DDR_DQ19_502
PS_DDR_DQ20_502
PS_DDR_DQ21_502
PS_DDR_DQ22_502
PS_DDR_DQ23_502
PS_DDR_DQ24_502
PS_DDR_DQ25_502
ZYNQ Pin Number
C2
B2
G2
F2
R2
T2
W5
W4
C3
B3
A2
A4
D3
D1
C1
E1
E2
E3
G3
H3
J3
H2
H1
J1
P1
P3
R3
R1
T4
U4
U2
U3
V1
Y3
