VisuNet Control Center 6
Manage (Device)
Session Shadowing
1.
Connect to an RM/BTC by clicking the icon or the minimized live view of the shown RM/BTC
screen and share its current screen. The function also allows remote control of an RM/BTC.
Figure 7.31
The session shadowing tile shows a minimized live view of the RMs/BTCs current screen.
This allows the VisuNet CC user to get an overview of the RMs/BTCs current status.
2.
For a detailed view of the RMs/BTCs screen, click the tile. This opens a new window that allows
the user to shadow the RM/BTC or remotely control the system.
The RM/BTC screen is displayed in the session shadowing window. The screen of the
RM/BTC is scaled to the current size of the session shadowing window. Using the "Enable
Fullscreen" function, the window can be maximized to show the native resolution of the
RM/BTC screen in the VisuNet CC window.
3.
While shadowing a session, you can click the Task Switcher
screen to open the RM Shell Task Switcher. This tool allows you to change open protocol
connections on the monitored device.
50
Shadowing the Session of an RM user
Note
The desktop sharing function must be enabled in the RM Shell to use this
feature.
in the upper-left corner of the
