6100 Series Manual Contents Preface ................... 5 1.1 Information on This Manual ................. 5 1.2 Responsibility of the Operator and/or Installer ......... 5 Safety ..................... 6 2.1 Introduction ....................6 2.1.1 Contents ..........................6 2.1.2 Target Group, Personnel ......................6 2.1.3 Symbols Used ........................7 2.1.4 Pertinent Laws, Standards, Directives, and Further Documentation ........7 2.1.5 Declaration of Conformity ......................7 2.2 Warning Labels .....................
Page 4
6100 Series Manual Contents Operation ..................26 6.1 Turning on Power to the Enclosure ............26 6.2 Turning off Power to the Enclosure ............27 6.3 6100 Series Components ................28 6.4 Setup Procedures ..................33 6.5 Operation in Gas-Hazardous Locations ........... 34 6.6 Programming ....................
6100 Series Manual Preface Preface We are pleased that you have chosen a quality product from Pepperl+Fuchs. This manual will help you meet the safety and protection requirements for installing, commissioning, and using the 6100 purge and pressurization system and its components.
6100 Series Manual Safety Safety Introduction 2.1.1 Contents This document contains information that you need to use your product throughout the applicable stages of the product life cycle. These can include the following: Product identification Delivery, transport, and storage ...
6100 Series Manual Safety 2.1.3 Symbols Used This document contains symbols for the identification of warning messages and of informative messages. Warning Messages You will find warning messages in instances where danger may arise from your actions. You must observe these warning messages for your personal safety and to avoid property damage.
6100 Series Manual Safety Warning Labels WARNING—FOR PRESSURIZED ENCLOSURES IN HAZARDOUS GAS ENVIRONMENTS This pressurized enclosure shall not be opened unless the area is known to be free of flammable materials or unless all devices have been de-energized. Power must not be restored after the pressurized enclosure has been opened until the pressurized enclosure is completely purged of all hazardous gas and the enclosure re-pressurized.
6100 Series Manual Safety EPV-6100 Enclosure Protection Vent The EPV has an operating temperature class of 135 °C (T4 temperature class). This temperature shall be considered when mounted to an enclosure. Cables use to connect the EPV must be provided with at least 0.25 mm insulation thickness per conductive core to maintain segregation between intrinsically safe circuits.
Product Description Overview The purpose of the Pepperl+Fuchs Bebco EPS 6100 series Ex pxb, Zone 1 large enclosure / motor purge and pressurization system is to allow general purpose or non-rated electrical equipment located in a general purpose enclosure to operate in Zone 1 locations. Other purposes of the 6100 series system include heat, moisture, and dust contamination prevention.
6100 Series Manual Product Description, System Components System Components 3.2.1 6100-MP-EX-* Control Unit User-interface controller (UIC) Inlet for purge gas supply—1 1/4" FNPT Outlet for purge gas supply into enclosure— 1 1/4" FNPT Intrinsically safe pilot valve supply port 1/4" tube compression fitting Manual gate valve for pressurization Angle valve for purging...
6100 Series Manual Product Description, Technical Data Technical Data 3.3.1 6100-MP-EX-* Control Unit General specifications Operating mode manual, semi-automatic, or fully automatic - programmable Series 6100 Number of volume exchanges 4 to 19 Hazardous environment Supply Rated voltage U 100 ... 250 V AC, 48 ... 62 Hz / 0.2 A 20 ...
Page 14
6100 Series Manual Product Description, Technical Data Pneumatic parameters Protective gas supply regulated and filtered air or inert gas Pressure requirement regulated side: 20 ... 120 psig (1.4 ... 8.3 bar) unregulated side: 60 ... 120 psig (4.1 ... 8.3 bar) Safe pressure 0.25 in wc (6.4 mm wc) (0.625 mbar) minimum for 6100-MP-LPP-* Purge flow and enclosure pres-...
6100 Series Manual Product Description, Technical Data General information Supplementary information EC-Type Examination Certificate, Statement of Conformity, Declaration of Conformity, Attestation of Conformity and instructions have to be ob- served where applicable. For information see www.pepperl- fuchs.com. Supplemental Standards : EN 61010-1:2010 3.3.2 6100-MP-LPP-* Pressure Sensor General specifications...
6100 Series Manual Product Description, Technical Data International approvals IECEx approval IECEx CML 19.0156X Ex db eb ib [ib Gb][pxb Gb] IIC T4 Gb General information Supplementary information EC-Type Examination Certificate, Statement of Conformity, Decla- ration of Conformity, Attestation of Conformity and instructions have to be observed where applicable.
Page 17
6100 Series Manual Product Description, Technical Data Data for application in connection with hazardous areas Certificate CML 19 ATEX 1425X Marking II2G Ex db eb ib [ib Gb][pxb Gb] IIC T4 Gb Directive conformity Directive 2014/34/EU EN IEC 60079-0:2018 EN 60079-1:2014 EN 60079-2:2014 EN 60079-7:2015 EN 60079-11:2012...
6100 Series Manual Product Description, Dimensions Dimensions N O T R E L E A S E D 3.4.1 6100-MP-EX-* Control Unit Note! The purge controller is equipped with a stud for equipotential bonding. N O T R E L E A S E D N O T R E L E A S E D...
6100 Series Manual Product Description, Dimensions N O T R E L E A S E D 3.4.2 EPV-6100-MP-* Vent N O T R E L E A S E D N O T R E L E A S E D 104-5528 Not released EDM checkout 11/01/2019 N O T R E L E A S E D...
6100 Series Manual Product Description, Dimensions 3.4.4 6000-TEMP-01 Temperature Hub 94.0 mm (3.70") Twinsburg, OH 44087 USA / www.pepperl-fuchs.com 6000-TMP-01 POWER Part No. 514202 FAULT 21.5 mm 6000 X-PURGE TEMPERATURE HUB (.85") 35 mm DIN rail or panel mounted 3.4.5 6000-TSEN-01 Temperature Sensor Note! 6000-TSEN-01 must be used with the 6000-TEMP-01 temperature hub.
6100 Series Manual 6100-MP-EX-AC-01 CERTIFICATION MARKINGS Product Description, Labels and Markings Labels and Markings N O T R E L E A S E D 68307 Mannheim, Germany www.pepperl-fuchs.com Model: 6100-MP-EX-AC-01 II 2G Ex db eb ib [ib Gb] [pxb Gb] IIC T4 Gb EPV-6100 CERTIFICATION MARKINGS 0539 IECEx CML 19.0156X...
6100 Series Manual Electrical Installation Danger! To prevent ignition of the flammable atmospheres, the wiring method must ensure that if any wire is disconnected and extended to the opposite terminal, a 2-inch separation must be maintained. For Wires Going to the DIN-Rail-Mount I.S. Board in the 6100 Control Unit: 1.
6100 Series Manual Electrical Installation Caution! Maintain a minimum space of 2" (50.8 mm) between the I.S. wiring and the non-I.S. wiring. Make sure that the wiring is neatly tucked into the explosion-proof housing. Use wire ties if necessary. As a rule, no wires are to be in the area between the two terminals.
6100 Series Manual Pneumatic Requirements Pneumatic Requirements Protective Gas Supply The protective gas supply to the enclosure system must be a clean quality compressed air or inert gas. The protective gas supply compressor intake must originate in a nonhazardous location. The suction duct passing through a hazardous location and the protective tubing and piping must be fabricated from noncombustible material suitable for the prevailing hazardous and environmental conditions.
6100 Series Manual Operation Operation Turning on Power to the Enclosure Door open input off or not used No door open Immediate No immediate shutdown shutdown input off or not used Overload/temp input off or overload/temp not used 6100-LPP > minimum overpressure <...
6100 Series Manual Operation Turning off Power to the Enclosure Control power relay input broken/shorted Control power relay Control power relay input Door open input broken/shorted Door open Door open input on Immediate shutdown input broken/shorted Immediate shutdown Overload/temp input Immediate shutdown broken/shorted input on...
6100 Series Manual Operation 6100 Series System Components The 6100 series consists of the 6100-M_-EX-__-__ control unit, which includes the pneumatic components for purging and pressurization and user interface, the EPV-6100-MP-__ enclosure vent, and the 6100-MP-LPP-01 pressure sensor. All three device are separate items. Optional temperature sensing devices are available for temperature monitoring/control.
Page 29
6100 Series Manual Operation Electronic Power Control Unit—EPCU The EPCU houses the redundant microprocessors, enclosure power contacts, (2) auxiliary contacts, power supply module, galvanically isolated barriers for the inputs, vent(s), and temperature modules. The EPCU is easy to remove and install into the explosion-proof enclosure that houses it. The EPCU is available in 20 ...
Page 30
6100 Series Manual Operation Note! The following parameters must be entered for the purge time: Enclosure volume Number of exchanges Type of vent for flow rate—enter flow rate Minimum purge time is 2 min. Fixed Purge Time The purge time is based on the known enclosure volume, number of volume exchanges, and flow rate through the vent.
Page 31
6100 Series Manual Operation The "ON PRESSURE" is the lowest pressure you want in the enclosure and will start the control action on when pressure goes below this value. The "OFF PRESSURE" is when the valve shuts off. When the pressure is between these two values, nothing will happen.
Page 32
6100 Series Manual Operation Danger! Do not use auxiliary contact for power to enclosure(s). Danger! If powering auxiliary equipment with auxiliary 1 or auxiliary 2 outputs, the wiring methods used must be suitable for the hazardous area. Temperature Inputs The 6000-TEMP-01 temperature hub and 6000-TSEN-01 external temperature sensor(s) are designed to work only with the 6000 purge and pressurization system.
6100 Series Manual Operation EPV-6100 I.S. Relief Vent The EPV-6100 vent exhausts excess pressure from the enclosure when the enclosure pressure exceeds the breaking pressure of the vent's relief mechanism. This pressure is usually around 3 mbar (1.2 in wc). The EPV-6100 also has an internal measured orifice plate with a differential pressure sensor to detect pressure across this orifice plate to be converted to a flow rate.
6100 Series Manual Operation may need to be increased. The latter may cause the system to drop out of operation and require purging again because it dropped below the minimum pressure value. 8. The system is now ready to operate. Operation in Gas-Hazardous Locations Follow setup procedures for the 6100 series system above Enclosure is sealed.
6100 Series Manual Operation To cycle power to the unit, press the EXIT, Left Arrow, START/SET, and Right Arrow keys at the same time. This will cycle power to the EPCU without physically removing power. This re-cycle feature will de-energize the relays of the EPCU and reset the unit.This feature does not affect any of the settings in the menus of the EPCU.
6100 Series Manual Operation 6.6.12 Statistics This provides system operating information. These fields are read only. STATISTICS — TEMPERATURES — HUB SENSOR STATS — CURRENT HUB — CURRENT HUB TEMP TEMP XXX °F — MAX HUB TEMP — MAX HUB TEMP XXX °F —...
Page 44
6100 Series Manual Operation — MAX PURGE — MAX PURGE PRESSURE PRESSURE X.XX IN WC — LAST PURGE TIME — LAST PURGE TIME XXXX MIN — MIN PURGE FLOW — MIN PURGE FLOW XX CFM — MAX PURGE FLOW — MAX PURGE FLOW XX CFM —...
6100 Series Manual Operation 6.6.13 Alarm This provides the reason for the last system alarm. ALARM — NONE — NO SAFE PRESSURE — MAX PRESSURE — INPUT 1 BROKE/ SHORT — INPUT 2 BROKE/ SHORT — INPUT 3 BROKE/ SHORT —...
6100 Series Manual Operation 6.6.14 Fault This provides the reason for the system fault. FAULT — NONE — CONTROL OUTPUT 1 — CONTROL OUTPUT 2 — CONTROL VALVE — ENCLOSURE POWER RELAY — INPUT 1 — INPUT 2 — INPUT 3 —...
When checking whether the pressure and flow measurements of the EPV-6100 vent are within specifications, use calibrated equipment to determine measurements, or contact a Pepperl+Fuchs representative or the factory to send back the EPV-6100 vent for pressure and flow verification.
6100 Series Manual Alarm and Fault Conditions Alarm and Fault Conditions The 6100 purge controller can indicate certain alarm and fault conditions when they happen. The alarm condition is indicated on the display under the Alarm/Fault LED and will blink for an alarm and remain solid for a fault.
6100 Series Manual Alarm and Fault Conditions Fault Descriptions Fault Description Cause CONTROL VALVE The control valve circuit is not -I.S. barrier board fuse is blown functioning properly -Power supply to control unit is too INPUT 1-4 Input 1 ,2,3, or 4 is not functioning -I.S.
