Danfoss iC7 Series Operating Manual page 61

Functional Extension Options
Operating Guide
Default Value: 100000
Unit: Hz
7.6.3.5 Input T13 (Menu Index 9.5.5)
P 9.5.5.1 T13 Terminal Mode
Description: Select the mode for the terminal.
Default Value: 0 [Inactive]
Unit: -
The following are the selections for the parameter
Selection number
0
3
4
P 9.5.5.2 T13 Signal Inversion
Description: Select whether the signal of the terminal is inverted.
Default Value: 0 [Non-Inverted]
Unit: -
The following are the selections for the parameter
Selection number
0
1
P 9.5.5.3 T13 Fast Debounce Filtering Time
Description: Set the fast debounce filtering time for the terminal.
Default Value: 0.00
Unit: μs
P 9.5.5.4 T13 Standard Debounce Filtering Time
Description: Set the standard debounce filtering time for the terminal.
Default Value: 0.00
Unit: ms
P 9.5.5.5 T13 Pulse Min. Frequency
Description: Set the frequency representing 0% of the signal.
Default Value: 0
Unit: Hz
P 9.5.5.6 T13 Pulse Max. Frequency
Description: Set the frequency representing 100% of the signal.
Danfoss A/S © 2023.06
Parameter Type: Range (0 — 100000)
Data Type: REAL
Parameter Type: Selection
Data Type: UINT
Parameter Type: Selection
Data Type: UINT
Parameter Type: Range (0.00 — 63.50)
Data Type: REAL
Parameter Type: Range (0.00 — 127.00)
Data Type: REAL
Parameter Type: Range (0 — 100000)
Data Type: REAL
General Purpose I/O Installation
Parameter Number: 4959
Access Type: Read/Write
Parameter Number: 2015
Access Type: Read/Write
Selection name
Inactive
Digital input
Pulse input
Parameter Number: 2291
Access Type: Read/Write
Selection name
Non-Inverted
Inverted
Parameter Number: 2285
Access Type: Read/Write
Parameter Number: 2024
Access Type: Read/Write
Parameter Number: 2027
Access Type: Read/Write
AQ390830267692en-000601 / 136R0273 | 61
and Configuration
