Functional Extension Options
Operating Guide
X101
1
2
3
4
5
6
SL2.5
10 mm
(0.4 in)
Illustration 26: Inserting Wires into the Relay Option OC7R0 Connectors

6.5.1 Wiring Diagrams for Different Operating Altitudes

• Operation up to 2000 m (6560 ft) altitude: Each relay can operate at different phase voltages. See
• Operation above 2000 m (6560 ft) altitude: Operation with voltage above 50 V AC requires operation on the same phase volt-
age. See Illustration 28.
• Operation with mixed voltage (24 V) and high voltage is possible. High voltage must be on the same phase. See
Terminal X101
COM
1
Terminal X102
L1
COM
4
L2
L3
PE
Terminal X103
COM
7
Illustration 27: Operation up to 2000 m (6560 ft) Altitude
46 | Danfoss A/S © 2023.06
X102
X103
7
8
NO
2
3
NC
NO
5
6
NC
NO
8
Relay Option Installation and
Configuration
Illustration 27.
Illustration
AQ390830267692en-000601 / 136R0273
29.
