Danfoss iC7 Series Operating Manual page 60

Functional Extension Options
Operating Guide
P 9.5.3.6 T11 Pulse Out Max. Frequency
Description: Set the frequency representing 100% of the signal.
Default Value: 100000
Unit: Hz
7.6.3.4 Input T12 (Menu Index 9.5.4)
P 9.5.4.1 T12 Terminal Mode
Description: Select the mode for the terminal.
Default Value: 0 [Inactive]
Unit: -
The following are the selections for the parameter
Selection number
0
3
4
P 9.5.4.2 T12 Signal Inversion
Description: Select whether the signal of the terminal is inverted.
Default Value: 0 [Non-Inverted]
Unit: -
The following are the selections for the parameter
Selection number
0
1
P 9.5.4.3 T12 Fast Debounce Filtering Time
Description: Set the fast debounce filtering time for the terminal.
Default Value: 0.00
Unit: μs
P 9.5.4.4 T12 Standard Debounce Filtering Time
Description: Set the standard debounce filtering time for the terminal.
Default Value: 0.00
Unit: ms
P 9.5.4.5 T12 Pulse Min. Frequency
Description: Set the frequency representing 0% of the signal.
Default Value: 0
Unit: Hz
P 9.5.4.6 T12 Pulse Max. Frequency
Description: Set the frequency representing 100% of the signal.
60 | Danfoss A/S © 2023.06
Parameter Type: Range (0 — 100000)
Data Type: REAL
Parameter Type: Selection
Data Type: UINT
Parameter Type: Selection
Data Type: UINT
Parameter Type: Range (0.00 — 63.50)
Data Type: REAL
Parameter Type: Range (0.00 — 127.00)
Data Type: REAL
Parameter Type: Range (0 — 100000)
Data Type: REAL
General Purpose I/O Installation
Parameter Number: 4953
Access Type: Read/Write
Parameter Number: 4053
Access Type: Read/Write
Selection name
Inactive
Digital input
Pulse input
Parameter Number: 4955
Access Type: Read/Write
Selection name
Non-Inverted
Inverted
Parameter Number: 4956
Access Type: Read/Write
Parameter Number: 4957
Access Type: Read/Write
Parameter Number: 4958
Access Type: Read/Write
AQ390830267692en-000601 / 136R0273
and Configuration
