Functional Extension Options
Operating Guide
Functions
Maximum altitude
Protection rating
Ambient temperature
Weight
7.4.1 I/O Specifications
Control inputs and outputs are PELV galvanically isolated from supply voltage and other high voltage terminals, unless otherwise
specified.
Analog Input
Table 30: Analog Input
Function
Input modes
Voltage mode
Current mode
Resolution
Accuracy
Reaction time
Temperature sensor support
The selection is made in the software. For more information, refer to the application guide.
1
External insulation of the sensor is required to comply with PELV.
2
Analog Output
Table 31: Analog Output
Function
Output range: Current
Minimum load resistor to GND
Resolution
Accuracy
Bandwidth
Reaction time
50 | Danfoss A/S © 2023.06
Data
Current or voltage
• Voltage range: -10 V to 10 V (scalable)
• Input impedance: 10 kΩ
• Maximum voltage: +12 V/-12 V
• Current range: 0/4-20 mA (scalable)
• Input impedance: 200 Ω
• Maximum current: 24 mA
0.1% of full scale
1% of full scale
< 1 ms
1xPt100, 2x Pt100, 3xPt100, Pt1000, Ni1000 (A/B), KTY81, KTY82, KTY84
(2)
Data
4400 m (14400 ft)
IP00/UL Open Type
-30 °C...60 °C (-22 °F...140 °F)
0.113 kg (0.25 lb)
(1)
Data
0/4-20 mA
500 Ω
0.1% of full scale
1% of full scale
440 Hz
< 1 ms
General Purpose I/O Installation
and Configuration
