Danfoss iC7 Series Operating Manual page 58

Functional Extension Options
Operating Guide
The following are the selections for the parameter
Selection number
0
1
2
3
P 9.5.1.3 T7 Pulse Out Min. Frequency
Description: Set the frequency representing 0% of the signal.
Default Value: 0
Unit: Hz
P 9.5.1.4 T7 Pulse Out Max. Frequency
Description: Set the frequency representing 100% of the signal.
Default Value: 100000
Unit: Hz
7.6.3.2 Output T8 (Menu Index 9.5.2)
P 9.5.2.1 T8 Terminal Mode
Description: Select the mode for the terminal.
Default Value: 0 [Inactive]
Unit: -
The following are the selections for the parameter
Selection number
0
1
2
P 9.5.2.2 T8 Digital Output Type
Description: Select the operating logic for the digital output.
Default Value: 0 [Tri state]
Unit: -
The following are the selections for the parameter
Selection number
0
1
2
3
P 9.5.2.3 T8 Pulse Out Min. Frequency
Description: Set the frequency representing 0% of the signal.
58 | Danfoss A/S © 2023.06
Selection name
Tri state
Open collector sink (NPN)
Open collector source (PNP)
Push pull
Parameter Type: Range (0 — 100000)
Data Type: REAL
Parameter Type: Range (0 — 100000)
Data Type: REAL
Parameter Type: Selection
Data Type: UINT
Parameter Type: Selection
Data Type: UINT
Selection name
Tri state
Open collector sink (NPN)
Open collector source (PNP)
Push pull
General Purpose I/O Installation
Parameter Number: 4942
Access Type: Read/Write
Parameter Number: 4943
Access Type: Read/Write
Parameter Number: 4944
Access Type: Read/Write
Selection name
Inactive
Digital Output
Pulse Output
Parameter Number: 4945
Access Type: Read/Write
AQ390830267692en-000601 / 136R0273
and Configuration
