Danfoss iC7 Series Operating Manual page 57

Functional Extension Options
Operating Guide
Selection number
0
5
P 9.4.3.2 T4 Terminal Type
Description: Select the type of the terminal. If voltage is selected, the unit is V. If current is selected, the unit is mA.
Default Value: 0 [Off]
Unit: -
The following are the selections for the parameter
Selection number
0
1
2
P 9.4.3.3 T4 Minimum Value
Description: Set the voltage or current representing 0% of the signal.
Default Value: 0
Unit: -
P 9.4.3.4 T4 Maximum Value
Description: Set the voltage or current representing 100% of the signal.
Default Value: 10
Unit: -
7.6.3 Digital Inputs/Outputs (Menu Index 9.5)
7.6.3.1 Output T7 (Menu Index 9.5.1)
P 9.5.1.1 T7 Terminal Mode
Description: Select the mode for the terminal.
Default Value: 0 [Inactive]
Unit: -
The following are the selections for the parameter
Selection number
0
1
2
P 9.5.1.2 T7 Digital Output Type
Description: Select the operating logic for the digital output.
Default Value: 0 [Tri state]
Unit: -
Danfoss A/S © 2023.06
Parameter Type: Selection
Data Type: UINT
Parameter Type: Range (0 — 20)
Data Type: REAL
Parameter Type: Range (0 — 20)
Data Type: REAL
Parameter Type: Selection
Data Type: UINT
Parameter Type: Selection
Data Type: UINT
General Purpose I/O Installation
Selection name
Inactive
Analog Output
Parameter Number: 4936
Access Type: Read/Write
Selection name
Off
Voltage
Current
Parameter Number: 4937
Access Type: Read/Write
Parameter Number: 4938
Access Type: Read/Write
Parameter Number: 4940
Access Type: Read/Write
Selection name
Inactive
Digital Output
Pulse Output
Parameter Number: 4941
Access Type: Read/Write
AQ390830267692en-000601 / 136R0273 | 57
and Configuration
