Danfoss iC7 Series Operating Manual page 25

Functional Extension Options
Operating Guide
17
15
9
7
3
5
2
1
18
16
14
12
10
8
6
4
13
11
Illustration 12: Wiring Configuration for SinCos Encoder
1 Encoder
5.5.7 SSI Encoder
Absolute position is read from the encoder and used to set the actual position after power-up.
Table 14: Parameters for SSI Encoder
Parameter
9.4.1 Interface Configuration
9.4.4 Encoder Supply Voltage
9.6.1 Singleturn Resolution
9.6.2 Multiturn Resolution
9.6.5 BiSS/SSI Clock Rate
Danfoss A/S © 2023.06
A+
A–
B+
B–
Setting
Select [17] SSI Z,D.
Set the appropriate supply voltage.
Voltage can be up to 24 V. Setting the voltage too high can damage the connected encoder.
Set the number of bits used for 1 revolution.
Set the number of bits used for revolution count.
Set the clock rate used for SSI or BiSS.
Encoder/Resolver Installation and
1
N O T I C E
AQ390830267692en-000601 / 136R0273 | 25
Configuration
