LED and Button

Note
The LED description applies to both fit and fat modes unless otherwise specified.
Table 1-8 LED Status
Status
Off
Steady green
Steady red
Blinking red at an
interval of 1s
Blinking blue at an
interval of 0.2s
Steady blue
Blinking blue at an
interval of 1s
Blinking red at an
interval of 0.2s
and
RG-AP680-CD(V3)
IP68
24d salt spray test
GB 4943.1, IEC 60950-1, IEC 60825-1
EN 300386, GB/T 19286, GB/T 17618
Frequency
N/A
N/A
N/A
On for 3s
Off for 1s
On for 0.2s
Off for 0.2s
N/A
On for 1s
Off for 1s
On for 0.2s
Off for 0.2s
Description
The access point is not powered on.
The access point is powered on, but the LED is manually
turned off.
The software system of the access point is being
initialized.
The system is running properly, but the uplink service port
is linked down.
In fit mode, the setup of a CAPWAP tunnel between the
access point and wireless controller timed out.
In fit or MACC mode, the software system of the AP is
being updated.
The system is running properly, but there is no STA
online.
The system is running properly and there are one or more
STAs online.
In fit mode, the access point is being located.
