Due to product version upgrades or other reasons, the content of this document will be updated from time to time. Ruijie Networks reserves the right to modify the content of the document without any notice or prompt.
Preface Intended Audience This document is intended for: Network engineers Technical support and servicing engineers Network administrators Technical Support Ruijie Networks website: https://www.ruijienetworks.com/ Technical support website: https://ruijienetworks.com/support Case portal: https://caseportal.ruijienetworks.com Community: https://community.ruijienetworks.com Technical support Email: service_rj@ruijienetworks.com...
Page 4
Specification An alert that contains a description of product or version support. 2. Note This manual provides the device installation steps, hardware troubleshooting, module technical specifications, and specifications and usage guidelines for cables and connectors. It is intended for the users who have some experience in installing and maintaining network hardware.
1.775 Gbps, with up to 575 Mbps in the 2.4 GHz band and 1200 Mbps in the 5 GHz band. The RG-AP680(CD) AP provides one 1GE SFP port and one 1GE Ethernet port, which can work at the same time.
Technical Specifications 1.3.1 Dimensions and Weight Table 1-1 Dimensions and Weight Dimensions and RG-AP680(CD) Weight Dimensions (W × D 251 mm × 168 mm × 64 mm (9.88 in. x 6.61 in. x 2.52 in.) × H) Weight 1.5 kg (3.31 lbs.)
Page 9
Hardware Installation and Reference Guide Product Introduction Radio RG-AP680(CD) Specifications Radio 2: 5 GHz, two spatial streams: 2 x 2, MU-MIMO Radio 1: 802.11b/g/n/ax, 2.400 GHz to 2.4835 GHz Operating Radio 2: 802.11a/n/ac/ax, 5.150 GHz to 5.350 GHz, 5.725 GHz to frequencies 5.850 GHz...
Hardware Installation and Reference Guide Product Introduction 1.3.4 Power Supply and Consumption Table 1-4 Power Supply and Consumption Power Supply and RG-AP680(CD) Consumption 1. DC power supply (44 V to 57 V/0.35 Input power supply 2. PoE/PoE+ (IEEE 802.3af/at-compliant) Max. power 12.95 W...
GB 4943.1, IEC 60950-1 EMC standard EN 301 489, EN 55022 LED and Button The RG-AP680(CD) has multiple LEDs, including one SYS LED and RSSI LEDs. The status of LEDs is described as follows. Table 1-6 LEDs of the RG-AP680(CD)
Page 13
Hardware Installation and Reference Guide Product Introduction Table 1-7 Reset Button of the RG-AP680(CD) Button Function Result Press the button for less than 2s to reboot the To reboot the AP device. Reset button To restore to factory Press and hold the button for over 3s to settings restore factory settings.
No additional lightning protector is required as a high-profile lightning protector is built in the RG-AP680(CD), and the power port support 6 kV lightning protection. If a lightning protector of a higher profile is available, configure the lightning protector as required.
Required Temperature and Humidity for the RG-AP680(CD) Working –40°C to +65°C (–40°F to +149°F) Temperature Working Humidity 0% to 100% (non-condensing) 2.2.2 Installation Methods The RG-AP680(CD) can be mounted on a wall or pole. 2.2.3 Waterproof Requirements Cap unused ports using dust caps to ensure waterproof.
Hardware Installation and Reference Guide Preparing Installation Figure 2-1 Dust Cap Connect the network cable, optical fiber jumper, and DC power cord to the AP after they pass through the corresponding waterproof plugs to ensure waterproof. For details, see Installing the Access Point.
ESD tools, multimeter, waterproof duct tape, and waterproof plaster Note The RG-AP680(CD) is not delivered with a tool kit. The tool kit is customer-supplied. Checking Before Installtion Note Please check your goods carefully against the package contents in this document. If you...
Hardware Installation and Reference Guide Installing the Access Point Installing the Access Point Note Before installing the AP, make sure you have carefully read the requirements described in Chapter 2. Installation Flowchart Before You Begin Carefully plan and arrange the installation location, networking mode, power supply, and cabling before installing the device.
Precautions The RG-AP680(CD) can be mounted on a wall or a pole with a diameter ranging from 50 mm to 140 mm (1.97 in. to 5.51 in.). Use the 304 stainless steel hose clamp delivered with the AP. If the diameter of the pole is out of this range, purchase the SUS304 hose clamp with a proper size for installation.
Page 20
Hardware Installation and Reference Guide Installing the Access Point Figure 3-1 Securing the Access Point to the Mounting Plate (2) Install the mounting bracket to a pole or wall. Pole mounting As shown in Figure 3-2, attach the mounting bracket to a pole by threading two hose clamps through openings of the mounting bracket.
Page 21
Hardware Installation and Reference Guide Installing the Access Point Figure 3-3 Attaching the Mounting Bracket to a Wall (3) Install the AP on the mounting plate to the mounting bracket. Use four M6 screws to join the mounting plate and the bracket. Adjust the orientation of the AP before tightening the screws.
Hardware Installation and Reference Guide Installing the Access Point After installation, check that all screws are tightened to prevent the device from falling down. Connecting Cables Note The waterproof materials are customer-supplied. Connecting the Grounding Cable The grounding cable needs to be made onsite. Connect one end of the grounding cable delivered with the device to the ground hole of the device through an OT terminal and the other end to the ground through another OT terminal.
Page 23
Hardware Installation and Reference Guide Installing the Access Point (1) Based on the distance from the AP to the power supply terminal, trim the network cable to a proper length and thread it through the mounting plate. (2) Thread the network cable through the cable gland assembly based on the sequence shown in Figure 3-6.
Page 24
Hardware Installation and Reference Guide Installing the Access Point (1) Select an LC-LC optical fiber jumper whose diameter ranges from 2.5 mm to 2.9 mm (0.10 in. to 0.11 in.). (2) A cable gland assembly includes four components: A (adapter base), B (split gasket), C (grommet), and D (compression cap).
Hardware Installation and Reference Guide Installing the Access Point (Optional) Connecting the DC Power Cord Note When the AP is powered by the DC power supply, its ports are facing downward. In this case, the AP can be protected against only splashing water. The DC power cord should be used together with the cable gland.
Page 26
Hardware Installation and Reference Guide Installing the Access Point Figure 3-10 Bundling Cables on Mounting Bracket Using a Cable Tie Requirement for the Minimum Cable Bend Radius The bend radius of a power cord, communication cable, or flat cable should be ○...
Page 27
Hardware Installation and Reference Guide Installing the Access Point Figure 3-11 Bundling Cables for Wall Mounting Twisting Bending After bundling up cables with cable ties, cut off the remaining part. The cut should ○ be smooth and trim, without sharp corners, as shown in Figure 3-12.
Hardware Installation and Reference Guide Appendix Appendix Connectors and Media 1000BASE-T/100BASE-TX/10BASE-T Port The 1000BASE-T/100BASE-TX/10BASE-T is a 10/100/1000 Mbps port with auto- negotiation, which supports auto MDI/MDIX Crossover at these three rates. The 1000BASE-T complies with IEEE 802.3ab standard, and uses up to 100 m (328.10 100-ohm CAT5e twisted pairs with higher...
Page 29
Hardware Installation and Reference Guide Appendix Table 4-3 shows the straight-through and crossover cable connections for the 100BASE- TX/10BASE-T. Table 4-3 Connections of the Twisted Pairs of the 100BASE-TX/10BASE-T Fiber-Optic Cable Connection For the optical ports, select single-mode or multimode fiber-optic cables for connections according to the optical module connected.
Appendix Mini-GBIC Module Models and Specifications Ruijie provides various Gigabit SFP modules (Mini-GBIC modules) for APs based on the interfaces of access controller modules. You can select the most suitable SFP modules as needed. This appendix describes the models and specifications of some of the Gigabit SFP modules for your reference.
Page 31
Hardware Installation and Reference Guide Appendix Mini- GBIC- 1310 –3 LH40 Mini- GBIC- –22 ZX50 Mini- GBIC- 1550 –22 ZX80 Mini- GBIC- –9 ZX100 Mini- GBIC-GT Note For the optical module with the transmission distance exceeding 40 km (24.85 miles) or above, add one in-line optical attenuator on the link to avoid the overload of the optical receiver when short single-mode fiber-optic cables are used.
Hardware Installation and Reference Guide Appendix Package Contents Table 4-5 Package Contents Item Quantity Remarks Access point Mounting plate Mounting bracket M5 x 10 mm machine screw M6 x 20 mm machine screw M6 x 50 mm expansion anchor For the Ethernet/PoE Cable gland assembly port and the DC power port...
Page 33
Hardware Installation and Reference Guide Appendix Item Quantity Remarks Ruijie Networks Wireless Product Pre-installed on the Management Software...
