Hardware Installation and Reference Guide
Figure 2-1 Dust Cap
Connect the network cable, optical fiber jumper, and DC power cable to the access point after they pass through
the corresponding waterproof plugs to ensure waterproof.
2.2.10

Other Requirements

Regardless of whether the device is installed on the wall or pole, the following conditions must be met:

Sufficient space is reserved at the air inlet and air vents of the device, to facilitate heat dissipation of the
device.

The installation site allows for proper cooling and ventilation.

The installation side is sturdy enough to support the weight of the device and its accessories.

The access point is properly grounded.
2.3

Tools

Table 2-3 Tools
Common tools
Special tools
Meters
Other tools
Note
The RG-AP680-CD(V3) is not shipped with a tool kit. You need to prepare a tool kit by yourself.
Cross screwdriver, Allen key, Ethernet cables and optical fibers, screws, diagonal plier, and
cable ties
Anti-static wrist strap, stripping plier, crimping plier, and wire cutter
Multimeter and bit error rate tester (BERT)
PC, display, and keyboard
14
Preparing for Installation
