- Page 1 Ruijie RG-AP130(W2) V2 Series Access Points Hardware Installation and Reference Guide 1.00...
- Page 2 Ruijie Networks reserves all copyrights of this document. Any reproduction, excerption, backup, modification, transmission, translation or commercial use of this document or any portion of this document, in any form or by any means, without the prior written consent of Ruijie Networks is prohibited. Exemption statement This document is provided “as is”.
- Page 3 It is intended for the users who have some experience in installing and maintaining network hardware. At the same time, it is assumed that the users are already familiar with the related terms and concepts. Obtaining Technical Assistance Ruijie Networks Website: https://www.ruijienetworks.com/ Technical Support Website: https://ruijienetworks.com/support...
-
Page 4: Product Overview
Product Overview · 1 Product Overview Ruijie RG-AP130(W2) V2 Wall AP is designed for wireless deployment in hotels, offices, residential buildings and settings alike. The dual-radio, dual-band AP supports concurrent operation of 802.11a/n/ac and 802.11b/g/n, delivering data rates of up to 300Mbps in 802.11n and 866.5Mbps in 802.11ac. -
Page 5: Product Image
Hardware Installation and Reference Guide Product Overview Dimensions · 116 mm x 86 mm x 39 mm (4.6 in x 3.4 in x 1.5 in) (W x D x H) Weight 0.24 kg Front: Four 10/100/1000Base-T LAN ports Service Ports Rear: One 10/100/1000Base-T WAN port Management Ports... -
Page 6: Led Indicators
Hardware Installation and Reference Guide Product Overview Figure 1-1 Image of RG-AP130(W2) V2 · PoE/UpLink port, which is on the rear, is the 10/100/1000Base-T WAN port (PoE-capable). Four 10/100/1000Base-T LAN ports are on the bottom. Figure 1-2 Side View of RG-AP130(W2) V2 Note 1. - Page 7 Hardware Installation and Reference Guide Product Overview Figure 1-3 Indicator on the AP · Indicator Fit AP Mode: State Frequency Meaning The AP is powered off, or the AP is in Silent mode. Fast blinking 2.5Hz (fast green before Initialization is in progress. The AP is operational. blinking green) solid green Fast blinking red...
-
Page 8: Power Sources
Input voltage range: 12V Rated current: 1A When powered through PoE, the AP can be used with Ruijie’s other products supporting 802.3af PoE. 1.5 Cooling Solution The AP adopts fanless design. Because it is installed in an 86-style faceplate on the wall, to guarantee airflow for proper... -
Page 9: Preparing For Installation
Hardware Installation and Reference Guide Preparing for Installation · 2 Preparing for Installation 2.1 Safety Suggestions RG-AP130(W2) V2 must be used inside the room. To ensure normal operation and a prolonged useful life of the equipment, the installation site must meet the following requirements. To prevent device damage and bodily injury, please read carefully the safety recommendations described in this chapter. -
Page 10: Emi Consideration
Hardware Installation and Reference Guide Preparing for Installation (Particles/m · Besides, the contents of salts, acids and sulfides in the air are also strictly limited for the equipment room. These substances can accelerate metal corrosion and the aging of some parts. Table 2-3 describes the limit of some hazardous gases such as SO S, NO and Cl... -
Page 11: Installing The Access Point
Hardware Installation and Reference Guide Installing the Access Point · 3 Installing the Access Point Make sure you have carefully read Chapter 2, and be sure that the requirements set forth in Chapter 2 have been met. 3.1 Installation Flowchart 3.2 Before You Begin To ensure normal operation and a prolonged useful life of the equipment, observe the following safety precautions: ... - Page 12 Hardware Installation and Reference Guide Installing the Access Point Keep the device clean and dust-free. · Disconnect the device before cleaning it. Do not wipe the device with a damp cloth. Do not wash the device with liquid. ...
- Page 13 Hardware Installation and Reference Guide Installing the Access Point Connect the uplink cable to the UpLink port. · Figure 3-3 Tighten Screws with a Screwdriver Slide down the AP into the plate Figure 3-4 Mounting the AP into the Plate Use an M3x4 screw to fasten the AP to the plate.
-
Page 14: System Debugging
Hardware Installation and Reference Guide System Debugging · 4 System Debugging 4.1 Setting up a Debugging Environment Use PoE to power the AP. PoE power supply To use a PoE device, make sure the peer end supports the IEEE 802.3af PoE standard. Then, connect the Ethernet cable to the uplink port (WAN) on the AP. -
Page 15: Powering Up The Ap
Hardware Installation and Reference Guide System Debugging · 4.2 Powering Up the AP 4.2.1 Checking before power-up Verify that the input voltage matches the specification of the AP. 4.2.2 Checking after power-up After powering up, it is recommended that you check the following items to ensure normal operation of the AP. ... -
Page 16: Monitoring And Maintenance
Hardware Installation and Reference Guide Monitoring and Maintenance · 5 Monitoring and Maintenance 5.1 Monitoring You can observe the LED to monitor the AP in operation. Fast blinking green followed by solid green: The AP is being initialized and is operational. ... -
Page 17: Troubleshooting Flowchart
Hardware Installation and Reference Guide Troubleshooting · 6 Troubleshooting 6.1 Troubleshooting Flowchart 6.2 Troubleshooting LED does not light up after the AP is powered on Verify that the power source is IEEE 802.11af compliant. And then verify that the cable is connected properly. Orange LED blinks after the Ethernet cable is connected Verify that the device at the other end of the Ethernet cable is working properly. -
Page 18: Appendix A Connectors And Media
Hardware Installation and Reference Guide Appendix A Connectors and Media · Appendix A Connectors and Media 1000BASE-T/100BASE-TX/10BASE-T The 1000BASE-T/100BASE-TX/10BASE-T is a 10/100/1000 Mbps auto-negotiation port that supports auto MDI/MDIX. Compliant with IEEE 802.3ab, 1000BASE-T requires Category 5e 100-ohm UTP or STP (STP is recommended) with a maximum distance of 100 meters (328 feet).
