Hardware Installation and Reference Guide
Table 1-9 Reset button
Button
Reset button
Table 1-10 Bridge LED
LED Color
N/A
Green
Green
Green
1.6

Optical Module

The type of the port on the device directly connected with the 2.5G SFP port on the access point can be an
optical port or electrical port. However, the negotiated rate varies depending on the port rate or optical module
used on both devices. For details, see Table 1-11 and Table 1-12.
Table 1-11 Rate Negotiation for an Optical Port on the Peer Device
Optical Port
Rate of
Access
Point
2.5 Gbps
1 Gbps
Operation
Press the button for less
than 2s
Press and hold the button
for longer than 5s
No. of Steady-on
Description
LED
The access point does not enable the bridge function.
N/A
The access point has enabled the bridge function, but bridging fails.
Bridging is successful, and the strength of the wireless signals dedicated
1
for bridging is less than –70 dBm.
Bridging is successful, and the strength of the wireless signals dedicated
1, 2
for bridging ranges from –70 dBm to –50 dBm.
Bridging is successful, and the strength of the wireless signals dedicated
1, 2, 3
for bridging is greater than –50 dBm.
Optical Module
Rate
1 Gbps
2.5 Gbps Not supported
1 Gbps 1 Gbps
Result
Reboot the device.
Restore to factory settings.
Negotiated Rate Supported by the Port on the Peer Device
1 Gbps/10
Gbps/Auto
Negotiation
Not supported
1 Gbps
8
Product Introduction
1 Gbps/2.5 Gbps/10
Gbps/Auto Negotiation
2.5 Gbps
1 Gbps
