- Page 1 Ruijie RG-AP630(IDA2) Series Access Points Hardware Installation and Reference Guide V1.6...
- Page 2 This document is provided “as is”. The contents of this document are subject to change without any notice. Please obtain the latest information through the Ruijie Networks website. Ruijie Networks endeavors to ensure content accuracy and will not shoulder any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.
- Page 3 It is intended for the users who have some experience in installing and maintaining network hardware. At the same time, it is assumed that the users are already familiar with the related terms and concepts. Obtaining Technical Assistance Ruijie Networks Website: https://www.ruijienetworks.com/ Technical Support Website: https://ruijienetworks.com/support...
-
Page 4: Product Overview
· 1 Product Overview The RG-AP630(IDA2) is a wireless access point (AP) designed by Ruijie for next-generation high-speed wireless LANs. Adhering to the latest 802.11ac Wave2 standard, the AP delivers an access rate of up to 1733Mbps+800Mbps. It features security, radio frequency (RF) control, mobile access, Quality of Service (QoS), and seamless roaming. In addition, it can be managed by RG-WS series wireless access controllers (ACs) to implement wireless data forwarding, security, and access control. -
Page 5: Product Appearance
Hardware Installation and Reference Guide Product Overview · Operating: 0% to 100% (non-condensing) · Humidity Storage: 0% to 100% (non-condensing) IP Rating IP68 Weight <2.5 kg (5.51 lbs) Safety Standards GB4943, EN60601-1-2 (medical care), UL/CSA 60950-1, EN/IEC 60950-1, EN/IEC 60950-22 EMC Standards GB9254-2008, EN301 489, EN55022, FCC Part15, RSS-210 Table 1-2 LEDs of RG-AP630(IDA2) -
Page 6: Front View
Hardware Installation and Reference Guide Product Overview · · 1.3 Front View Figure 1-2 RG-AP630(IDA2) Front View 2. Console port 1. 2.4GHz&5GHz antenna connector 4.10/100/1000 Base-T auto-sensing Note: 3.10/100/1000 Base-T auto-sensing Ethernet port Ethernet/PoE IN port 5. SFP combo port 6. - Page 7 Hardware Installation and Reference Guide Product Overview · Ruijie Networks Wireless Device · Piece Preinstalled Management Software...
-
Page 8: Preparing For Installation
Hardware Installation and Reference Guide Preparing for Installation · · 2 Preparing for Installation To prevent device damage and physical injury, please read carefully the safety recommendations described in this chapter. Recommendations do not cover all possible hazardous situations. 2.1 Grounding and Lightning Protection ... -
Page 9: Temperature And Humidity
Hardware Installation and Reference Guide Preparing for Installation · 2.2.1 Temperature and Humidity · Table 2-1 Required Temperature and Humidity for the RG-AP630(IDA2) Series Operating Temperature -40°C to 65°C (-40°F to 149°F) Operating Humidity 0% to 100% (non-condensing) 2.2.2 Outdoor Installation The AP can be installed outdoors and mounted on a wall or pole. -
Page 10: Fiber Connection
Hardware Installation and Reference Guide Preparing for Installation · Radiation interference occurs when energy (usually radio frequency energy) is emitted from a device and propagated · through space to disrupt other devices. The interference source can be part of disrupted system or a fully electrically isolated unit. -
Page 11: Installing The Access Point
Hardware Installation and Reference Guide Installing the Access Point · · 3 Installing the Access Point Before installing the AP, make sure you have carefully read the requirements described in Chapter 2. 3.1 Installation Flowchart... -
Page 12: Before You Begin
Hardware Installation and Reference Guide Installing the Access Point · · 3.2 Before You Begin Before you install the AP, verify that all the parts in the package contents are there and make sure that: The installation site meets temperature and humidity requirements. ... - Page 13 Hardware Installation and Reference Guide Installing the Access Point · Attach the tie rod to the mounting plate and fasten the rod with the M8x40 screws after AP is well-positioned See · Figure 3-3. Figure 3-3 Fixing the Tie Rod on the Mounting Plate ...
- Page 14 Hardware Installation and Reference Guide Installing the Access Point · Figure 3-5 Wall Mount · Vertical pole mount a. Attach the cross-shaped bracket to a vertical pole with a hose clamp and fasten the clamp with screws using the Phillips (crosshead) screwdriver.
-
Page 15: Adjusting Antenna Orientation
Hardware Installation and Reference Guide Installing the Access Point · Figure 3-7 Installing the AP on a Vertical Pole · The procedure of horizontal pole mount is similar as that of a vertical mount. If the diameter of the pole is out of the range, the hose clamp is customer-supplied. In this case, we strongly recommend you to use a 304 stainless steel hose clamp with thickness of 2.5mm at least. - Page 16 Hardware Installation and Reference Guide Installing the Access Point · Figure 3-9 Clockwise Horizontal Rotation (+60°) · (-60°to +60°horizontal rotation available) Figure 3-10 Vertical Rotation (0°) Figure 3-11 Clockwise Vertical Rotation (+60°) (0°to 90° vertical rotation available)
- Page 17 Hardware Installation and Reference Guide Installing the Access Point · · 3.6 Installing a Security Lock (Optional) The security lock is customer-supplied. The lock loop on the AP is for your security needs. You can fasten the AP to a fixture as follows: Fasten the cable of a security lock to a fixture;...
- Page 18 Hardware Installation and Reference Guide Installing the Access Point · Figure 3-14 Threading the Network Cable · Wrap the cable between B and C upwards with two or three layers of liquid-tight material. See Figure 3-15. Figure 3-15 Wrapping Liquid-tight Material around Cable Insert the plug into the PoE IN port and tighten B, C and D in order.
-
Page 19: Installing Outdoor Antennas (Optional)
Hardware Installation and Reference Guide Installing the Access Point · If the diameter of LC-LC fiber is not 2.7±0.2mm, waterproofness of the adapter cannot be guaranteed. · 3.8 Installing Outdoor Antennas (Optional) The integrated RG-AP630(IDA2) antenna meets most requirements. To obtain external antennas for special applications, go to http://www.ruijienetworks.com/. - Page 20 Hardware Installation and Reference Guide Installing the Access Point · ·...
-
Page 21: Appendix A: Connectors And Media
Hardware Installation and Reference Guide Appendix A: Connectors and Media · · Appendix A: Connectors and Media 1000BASE-T/100BASE-TX/10BASE-T The 1000BASE-T/100BASE-TX/10BASE-T is a 10/100/1000 Mbps auto-negotiation port that supports auto MDI/MDIX. Compliant with IEEE 802.3ab, 1000BASE-T requires Category 5e 100-ohm UTP or STP (STP is recommended) with a maximum distance of 100 meters (328 feet). - Page 22 Hardware Installation and Reference Guide Appendix A: Connectors and Media · Fiber Connection · You can choose to use single mode or multimode fibers according to the transceiver module types. Figure A-4 shows connection of fiber cables. Figure A-4 Fiber Connection...
-
Page 23: Appendix B: Mini-Gbic Module Specifications
· Appendix B: Mini-GBIC Module Specifications Ruijie provides various Gigabit SFP transceivers (Mini-GBIC modules) for interfaces of wireless access controllers. You can select the most suitable SFP modules as needed. This appendix describes the models and specifications of some of the Gigabit SFP transceivers for your reference.
