Hardware Installation and Reference Guide
1.4

Technical Specifications

1.4.1

Dimensions and Weight

Table 1-3 Dimensions and Weight
Dimensions and
Weight
Dimensions (W × D × H)
Weight
Installation Mode
Anti-Theft Lock
Mounting Bracket
Dimensions (W × D × H)
Mounting Hole Pattern
Mounting Hole Diameter
Pole Diameter
1.4.2

RF Specifications

Table 1-4 RF Specifications
RF Specifications
Radio Design
Operating Band
Data Rate
RG-AP680-CD(V3)
251 mm × 168 mm × 64 mm (9.88 in. x 6.61 in. x 2.52 in.)
Access point: 1.5 kg (3.31 lbs.)
Mounting plate: 0.2 kg (0.44 lbs.)
Wall mounting and pole mounting
Not supported
115 mm × 115 mm × 126 mm
90 mm × 43.3 mm (3.54 in. x 1.70 in.)
8 mm (0.31 in.)
40 mm to 70 mm (1.57 in. x 2.76 in.)
RG-AP680-CD(V3)
Dual-radio
Up to four spatial streams
Radio 1: 2.4 GHz, 2 spatial streams: 2×2, MU-MIMO
Radio 2: 5 GHz, 2 spatial streams: 2×2, MU-MIMO
Radio1: 802.11b/g/n/ax, 2.4 GHz to 2.483 GHz
Radio2: 802.11a/n/ac/ax, 5.150 GHz to 5.350 GHz, 5.470GHz to 5.850GHz
Note: The operating bands vary in different countries.
Radio1: 2.4 GHz, 575 Mbps
Radio2: 5 GHz, 2.4 Gbps
Max. Data Rate:
2.4 GHz + 5 GHz: 2.975 Gbps
4
(4.53 in. x 4.53 in. x 4.96 in.)
