Hardware Installation and Reference Guide
This product uses a fanless design. When placing the AP, ensure that there is enough space around

to facilitate air circulation.
By default, the AP works in the 802.3at power feeding mode. To enable bt-related functions, run

commands.
If 802.3af is used for power feeding, when the AP starts, the 2.4 GHz and 5 GHz frequencies can only

work in 1-stream mode, and the LAN2 port and USB port cannot supply power to external devices.
If 802.3at is used for power feeding, when the AP starts, the LAN2 port and USB port cannot supply

power to external devices.

Environment and Reliability

1.4.5
Standards Compliance
Table 1-7
Environment and
Reliability
Temperature
Humidity
Safety regulation
EMC regulation

LED and Button Description

1.5
Note
In the description of the indicator status, unless otherwise specified, the indicator status description
applies to both Fit AP and Fat AP.
RG-SAP845-SP
Working temperature: -10°C to 50°C (14°F to 122°F)
Storage temperature: -40°C to 70°C (–40°F to +158°F)
At a height between 3000 m (9842.52 ft.) and 5000 m (16404.20 ft.) above
the sea level, every time the altitude increases by 220 m (721.78 ft.), the
maximum temperature decreases by 1°C (1.8°F).
Working humidity: 5%RH to 95%RH (non-condensing)
Storage humidity: 5%RH to 95%RH (non-condensing)
EN 300 328，EN 301 893，EN 300 440，FCC Part 15，EN IEC 62311，IEC
62368-1，EN 62368-1
EN 55032，EN 55035，EN 61000-3-3，EN IEC 61000-3-2，EN 301 489-1，EN
301 489-3，EN 301 489-17
8
Product Overview
