RF Specifications
Antenna Type
Antenna Gain
Max. Transmit Power
Transmit Power
Adjustment
Modulation Modes
Receiver Sensitivity
1.4.3

Port Specifications

Table 1-5 Port Specifications
Port Specifications
Bluetooth
Fixed Service Port
RG-AP680-CD(V3)
Built-in smart antenna
2.4 GHz: horizontal lobe angle of 60 degrees and vertical lobe angle of 30 degrees
5 GHz: horizontal lobe angle of 60 degrees and vertical lobe angle of 30 degrees
2.4 GHz: 9 dBi
5 GHz: 9 dBi
28 dBm
Note: The transmit power varies based on the regulations in different countries and
regions.
Configurable in increments of 1 dBm
802.11b: BPSK, QPSK, CCK
802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM
802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM
802.11ax: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM
802.11b: –96 dBm(1Mbps), –93 dBm(5Mbps), –89 dBm(11Mbps)
802.11a/g: –91 dBm(6Mbps), –85 dBm(24Mbps), –80 dBm(36Mbps),
–74dBm(54Mbps)
802.11n: –90 dBm@MCS0, –70 dBm@MCS7, –89 dBm@MCS8, –68
dBm@MCS15
802.11ac HT20: –88 dBm(MCS0), –63 dBm(MCS9)
802.11ac HT40: –85dBm(MCS0), –60 dBm(MCS9)
802.11ac HT80: –85 dBm(MCS0), –60 dBm(MCS9)
802.11ax HE80: –82 dBm(MCS0), -57 dBm(MCS9）,-52 dBm(MCS11)
802.11ax HE160: –45 dBm(MCS10), –43 dBm(MCS11)
RG-AP680-CD(V3)
Bluetooth 5.1
Uplink: One 10/100/1000Base-T
5
Ethernet port with auto-negotiation, compliant with
