- Page 1 Ruijie RG-AP680P-L Access Point Hardware Installation and Reference Guide Document Version: V1.0 Date: 2023.09.19 Copyright © 2023 Ruijie Networks...
- Page 2 Due to product version upgrades or other reasons, the content of this document will be updated from time to time. Ruijie Networks reserves the right to modify the content of the document without any notice or prompt. This manual is for reference only. Ruijie Networks endeavors to ensure content accuracy and will not shoulder any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.
-
Page 3: Preface
Preface Intended Audience This document is intended for: Network engineers Technical support and servicing engineers Network administrators Technical Support Ruijie Networks Website: https://www.ruijienetworks.com/ Technical Support Website: https://ruijienetworks.com/support Case Portal: https://caseportal.ruijienetworks.com Community: https://community.ruijienetworks.com ... - Page 4 2. Note The manual offers configuration information (including model, port type and command line interface) for indicative purpose only. In case of any discrepancy or inconsistency between the manual and the actual version, the actual version prevails.
-
Page 5: Table Of Contents
Contents Preface ..............................I 1 Product Introduction ........................... 1 1.1 Overview ............................ 1 1.2 Product Appearance ........................2 1.3 Package Contents........................4 1.4 Technical Specifications ......................5 1.4.1 Dimensions and Weight ....................5 1.4.2 Radio Specifications ...................... 5 1.4.3 Port Specifications ......................7 1.4.4 Power Supply and Consumption ................... - Page 6 2.2.4 Temperature/Humidity Requirements ................14 2.2.5 Grounding Requirements ..................... 14 2.2.6 Anti-interference Requirements ................... 15 2.2.7 Lightning Protection Requirements ................15 2.2.8 Waterproof Requirements .................... 16 2.2.9 Other Requirements ..................... 16 2.3 Tools ............................17 3 Installation ............................18 3.1 Installation Procedure ......................18 3.2 Before You Begin ........................
- Page 7 3.8 Installation Verification ......................27 3.8.1 Checking the AP ......................27 3.8.2 Checking Cable Connections ..................27 3.8.3 Checking the Power Supply ..................27 4 Verifying Operating Status ....................... 28 4.1 Establishing the Configuration Environment ................28 4.2 Powering on the AP ......................... 28 4.2.1 Checklist Before Power-on ..................
- Page 8 6.2.7 No Wireless Signal Searched ..................31 7 Appendix ............................32 7.1 Connectors and Media ......................32 7.2 Cabling Recommendations...................... 34 7.3 Optical Modules and Specifications ..................38...
-
Page 9: Product Introduction
Ruijie Access Controllers (ACs) and WIS to implement STA data forwarding, security, access control, and IoT application extension. Thanks to its IP68 rated housing, the RG-AP680P-L is suitable for use in extreme industrial environments and capable of effectively withstanding harsh weather and environments. It is highly adaptable to colder and wet climates, allowing for easier installation and maintenance. -
Page 10: Product Appearance
Hardware Installation and Reference Guide Product Introduction Product Appearance Figure 1-1 Front View Table 1-1 Description of Buttons and Ports on the Front Panel Item Description Uplink service port for data transmission, 5000Base-T LAN1/HPoE electrical Ethernet port with auto-negotiation port Support IEEE802.3af/802.3at/802.3bt-complaint PoE Downlink service port for data transmission, 1000Base-T Ethernet port with auto-negotiation... - Page 11 Hardware Installation and Reference Guide Product Introduction Figure 1-2 Rear View Table 1-2 Description of Buttons and Ports on the Rear Panel Item Description The port integrates the functions of a console port and a reset button. Console port/Reset The console port is used to connect with a serial cable button for device management.
-
Page 12: Package Contents
Hardware Installation and Reference Guide Product Introduction Package Contents Table 1-3 Package Contents Item Quantity Remarks Mounting bracket Support for pole-mounted or wall-mounted installation M5 x 10 machine screw M6 x 16 machine screw M8 x 20 machine screw M6 x 40 expansion anchor The rubber plug only has one hole Waterproof PG connector and adapts to network cables with a... -
Page 13: Technical Specifications
1.4.1 Dimensions and Weight Table 1-4 Dimensions and Weight Dimensions and RG-AP680P-L Weight Dimensions (W × D × 300 mm × 300 mm × 94 mm (11.81 in. x 11.81 in. x 3.70 in.) Main unit: 4.0 kg (8.82 lbs) Weight Mounting bracket: 1.5 kg (3.31 lbs) - Page 14 Hardware Installation and Reference Guide Product Introduction Radio Specifications RG-AP680P-L Note: The operating frequency is country-specific. Radio 1: 2.4 GHz, 1.147 Gbps Data rate Radio 2: 5 GHz, 4.804 Gbps Combined: 2.4 GHz + 5 GHz, 5.951 Gbps Antenna type Built-in smart antenna 2.4 GHz: 3 dBi...
-
Page 15: Port Specifications
2.5 Gbps/1 Gbps optical ports Downlink: One 10/100/1000Base-T Ethernet port with auto-negotiation, which allows the PSE to power external devices (802.3af, 15.4 W) and can connect to Ruijie IoT module Fixed management One RJ45 console port port One system status LED Status LED... -
Page 16: Environment And Reliability
Note: If the AP is powered by 802.3af PoE, only the CPU works. If the AP is powered by 802.3at PoE, Radio 3 does not work and the AP does not supply power to external devices. External power Supported (Connect to Ruijie IoT module, 802.3af-compliant, support supply for 15.4 W output power) Max. power ≤... -
Page 17: Led And Button
Hardware Installation and Reference Guide Product Introduction Environment and RG-AP680P-L Reliability Anti-corrosion rating GB/T 2423.17 EN 55032, EN 55035, EN 61000-3-3, EN IEC 61000-3-2, EN 301 Regulatory 489-1, EN 301 489-3, EN 301 489-17, EN 300 328, EN 301 893, EN... -
Page 18: Optical Module
Hardware Installation and Reference Guide Product Introduction Status Frequency Description On for 0.2s Blinking red at an In fit mode, the AP is being located. interval of 0.2s Off for 0.2s Table 1-10 Reset button Button Operation Result Press the button for Reboot the device. - Page 19 Hardware Installation and Reference Guide Product Introduction Table 1-12 Rate Negotiation for an Optical Port on the Peer Device Negotiated Rate Supported by the Port on the Peer Optical Device Optical Port Rate Module Rate 1 Gbps/10 1 Gbps/2.5 Gbps/10 of the AP 1 Gbps Gbps/Auto...
-
Page 20: Preparing For Installation
Hardware Installation and Reference Guide Preparing for Installation Preparing for Installation Safety Precautions Note To avoid personal injury and device damage, carefully read the safety precautions before you install the device. The following safety precautions may not cover all possible dangers. 2.1.1 General Safety Precautions ... -
Page 21: Storage Security
Hardware Installation and Reference Guide Preparing for Installation Direct or indirect contact with high voltage or mains power supply via wet objects may cause fatal dangers. Observe local regulations and specifications during electric operations. Only personnel with relevant qualifications can perform such operations. ... -
Page 22: Space Requirements
Hardware Installation and Reference Guide Preparing for Installation 2.2.3 Space Requirements Maintain a minimum clearance of 0.4 m around the device to ensure proper cooling and ventilation. 2.2.4 Temperature/Humidity Requirements To ensure the normal operation and a prolonged service life of the AP, maintain an appropriate temperature and humidity in the installation environment. -
Page 23: Anti-Interference Requirements
Take electromagnetic shielding measures when necessary. 2.2.7 Lightning Protection Requirements The RG-AP680P-L can guard against lightning strikes. As an electric device, too strong lightning strikes may still damage the device. Take the following lightning protection measures: Ensure that the neutral point of the AC power socket is in good contact with the ground. -
Page 24: Waterproof Requirements
Hardware Installation and Reference Guide Preparing for Installation wire are properly connected. Ensure that the ground resistance is less than 5 ohms. In areas with high soil resistivity, reduce the soil resistivity via measures such as spreading resistivity reduction mixture around the grounding conductor. -
Page 25: Tools
Special ESD tools, crimping pliers, diagonal pliers, network cable pliers, and wire Tools stripper Meter Multimeter Relevant PC, display, and keyboard Devices Note The RG-AP680P-L is not delivered with a tool kit. The tool kit is customer-supplied. -
Page 26: Installation
Hardware Installation and Reference Guide Installation Installation The RG-AP680P-L must be installed at a fixed position. Caution Before installing the device, make sure that you have carefully read the requirements described in Chapter 2. Installation Procedure The installation steps are shown in the following figure. -
Page 27: Before You Begin
Hardware Installation and Reference Guide Installation Before You Begin Carefully plan and arrange the installation location, networking mode, power supply, and cabling before installing the device. Confirm the following requirements before installation: The installation location provides sufficient space for heat dissipation. ... -
Page 28: Installing The Device
Hardware Installation and Reference Guide Installation Installing the Device 3.4.1 Installing the Support for Wall-mounted Installation Use four M6 expansion screws (hole of 105 mm x 65 mm or 4.13 in. x 2.56 in.) to fix the support on the wall with the TOP label facing up. Figure 3-2 Installing the Support for Wall-mounted Installation 3.4.2... -
Page 29: Mounting Bracket And Device Installation
Hardware Installation and Reference Guide Installation Caution Use matching screws for the screw holes, and tighten the structural parts in different installation links. Tighten all fastening screws. If any screw is not installed, the device may vibrate violently, shift, or fall down. - Page 30 Hardware Installation and Reference Guide Installation Figure 3-5 Connecting the Mounting Bracket and Installation Pole Based on the Wall- mounted Direction Figure 3-6 Connecting the Mounting Bracket and Installation Pole Based on the Ceiling- mounted Direction (3) Mount the device with the installation pole installed to the fixed support. Use hooks on the installation pole to connect with the support, and tighten a M8 combined screw on the left and right sides.
-
Page 31: Removing The Device
Hardware Installation and Reference Guide Installation Figure 3-7 Connecting with the Support 3.4.4 Removing the Device Remove the AP according to the installation steps in reverse sequence. Installing an Optical Module Insert the selected optical module into the optical port on the device and ensure that the optical module is properly installed. -
Page 32: Connecting Cables
Hardware Installation and Reference Guide Installation Connecting Cables Note You need to prepare waterproof materials yourself. 3.6.1 Connecting the Ground Cable The ground cable needs to be made on site. Connect one end of the yellow/green ground cable delivered with the device to the ground hole of the device through an OT terminal and the other end to the ground through another OT terminal. -
Page 33: Connecting The Fiber-Optic Cable
Hardware Installation and Reference Guide Installation (2) Pass the network cable with a crystal connector through the waterproof PG connector based on the sequence shown in the following figure. Figure 3-10 Passing the Network Cable Through the Waterproof PG Connector (3) Insert the crystal connector of the network cable into the network port on the AP and tighten the waterproof PG connector based on the sequence of parts B, C, D, and E. -
Page 34: Bundling Cables
Hardware Installation and Reference Guide Installation Figure 3-11 Passing the Fiber-Optic Cable Through the Waterproof Connector (2) Insert the optical module into the optical port of the device, and insert the fiber-optic cable into the optical module connector. (3) Tighten part B of the waterproof connector on the device, combine parts C and D and place them into B, and tighten part E. -
Page 35: Bundling Description
Hardware Installation and Reference Guide Installation 3.7.2 Bundling Description After the cables are connected with the device through the waterproof plugs and power-on is normal, use a cable tie to bundle the cables on the support and then fix the cables neatly. Figure 3-12 Bundling the Cables on the Support Using a Cable Tie Caution... -
Page 36: Verifying Operating Status
Hardware Installation and Reference Guide Verifying Operating Status Verifying Operating Status Establishing the Configuration Environment Power on the AP through PoE. When setting up the environment, pay attention to the following: Verify that the AP is properly connected to the power source. ... -
Page 37: Monitoring And Maintenance
If the AP works in fat mode, you can log in to the AP remotely for maintenance. If the AP works in fit mode, you can use an AC to centrally manage and maintain the AP. Hardware Maintenance If the hardware is faulty, please contact Ruijie technical support. -
Page 38: Troubleshooting
Hardware Installation and Reference Guide Troubleshooting Troubleshooting General Troubleshooting Procedure Common Troubleshooting Procedures 6.2.1 Ethernet Port Is Not Working After the Ethernet Cable Is Plugged Verify that the device at the other end of the Ethernet cable is working properly. And then verify that the Ethernet cable is capable of providing the required data rate and is properly connected. -
Page 39: Led Is Steady Green
Hardware Installation and Reference Guide Troubleshooting 6.2.4 LED Is Steady Green The device performs initialization after power-on. During this period, the LED keeps steady green and does not turn normal blue until the initialization is completed. Note: If the steady green persists for an hour, the device initialization fails and the device is faulty. -
Page 40: Appendix
Hardware Installation and Reference Guide Appendix Appendix Connectors and Media 5000BASE-T/2500BASE-T/1000BASE-T/100BASE-TX/10BASE-T port The 5000BASE-T/2500BASE-T/1000BASE-T/100BASE-TX/10BASE-T port supports auto- negotiation of five rates and supports auto MDI/MDIX crossover at these five rates. Compliant with IEEE 802.3bz, the 5000BASE-T/2500BASE-T port requires at least Category 6 STP with a maximum distance of 100 m (328.10 ft). - Page 41 Hardware Installation and Reference Guide Appendix Table 7-2 Pinouts of the 100BASE-TX/10BASE-T Socket Plug Input Receive Data+ Output Transmit Data+ Input Receive Data- Output Transmit Data- Output Transmit Data+ Input Receive Data+ Output Transmit Data- Input Receive Data- 4, 5, 7, 8 Not Used Not Used Table 7-3 shows the straight-through and crossover cable connections for the 100BASE-...
-
Page 42: Cabling Recommendations
Hardware Installation and Reference Guide Appendix Cabling Recommendations During installation, route cable bundles upward or downward along the sides of the rack depending on the actual situation in the equipment room. All cable connectors should be placed at the bottom of the cabinet rather than be exposed outside of the cabinet. Power cords are routed beside the cabinet, and top cabling or bottom cabling is adopted according to the actual situation in the equipment room, such as the positions of the DC power distribution box, AC socket, or lightning protection box. - Page 43 Hardware Installation and Reference Guide Appendix ○ Cables of different types (such as power cables, signal cables, and ground cables) should be separated in cabling and bundling. Mixed bundling is not allowed. When they are close to each other, it is recommended that crossover cabling be adopted. In the case of parallel cabling, maintain a minimum distance of 30 mm between power cords and signal cables.
- Page 44 Hardware Installation and Reference Guide Appendix Figure 7-3 Binding Cables ○ Cables not to be assembled or remaining parts of cables should be folded and placed in a proper position of the cabinet or cable trough. The proper position indicates a position that will not affect device running or cause device damage or cable damage during debugging.
- Page 45 Hardware Installation and Reference Guide Appendix ○ Hard power cords should be fastened in the terminal connection area to prevent stress on terminal connection and cable. ○ Do not use self-tapping screws to fasten terminals. ○ Power cables of the same type and in the same cabling direction should be bundled up into cable bunches, with cables in cable bunches clean and straight.
-
Page 46: Optical Modules And Specifications
Hardware Installation and Reference Guide Appendix Optical Modules and Specifications We provide appropriate optical modules according to the port types. You can select the module to suit your specific needs. The following tables list the models and technical specifications of some optical modules for reference.
