Ruijie RG-AP680-CD(V3) Access Point
Hardware Installation and Reference Guide
Document Version: V1.0
Date: June 6, 2023
Copyright © 2023 Ruijie Networks

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RG-AP680-CD and is the answer not in the manual?

Questions and answers

Related Manuals for Ruijie RG-AP680-CD

Summary of Contents for Ruijie RG-AP680-CD

  • Page 1 Ruijie RG-AP680-CD(V3) Access Point Hardware Installation and Reference Guide Document Version: V1.0 Date: June 6, 2023 Copyright © 2023 Ruijie Networks...
  • Page 2 Due to product version upgrades or other reasons, the content of this document will be updated from time to time. Ruijie Networks reserves the right to modify the content of the document without any notice or prompt. This manual is for reference only. Ruijie Networks endeavors to ensure content accuracy and will not shoulder...

  • Page 3: Preface

    Preface Intended Audience This document is intended for:  Network engineers  Technical support and servicing engineers  Network administrators Technical Support  Ruijie Networks website: https://www.ruijienetworks.com/  Technical support website: https://ruijienetworks.com/support  Case portal: https://caseportal.ruijienetworks.com  Community: https://community.ruijienetworks.com ...

  • Page 4: Table Of Contents

    Contents Preface ..............................I 1 Product Introduction ........................... 1 1.1 Overview ............................ 1 1.2 Product Appearance ........................1 1.3 Package Contents........................3 1.4 Technical Specifications ......................4 1.4.1 Dimensions and Weight ....................4 1.4.2 RF Specifications ......................4 1.4.3 Port Specifications ......................5 1.4.4 Power Supply and Consumption ...................
  • Page 5 2.2.4 Temperature/Humidity Requirements ................11 2.2.5 Cleanness Requirements..................... 12 2.2.6 System Grounding Requirements ................12 2.2.7 Anti-interference Requirements ................... 13 2.2.8 Lightning Protection Requirements................13 2.2.9 Waterproof Requirements .................... 13 2.2.10 Other Requirements ....................14 2.3 Tools ............................14 3 Installation ............................15 3.1 Installation Procedure ......................
  • Page 6 3.7.2 Bundling Description ....................24 3.8 Installation Verification ......................24 3.8.1 Checking the Access Point ..................24 3.8.2 Checking Cable Connections ..................25 3.8.3 Checking the Power Supply ..................25 4 Commissioning ..........................26 4.1 Establishing the Configuration Environment ................26 4.2 Powering on the Access Point ....................
  • Page 7 6.2.6 LED Does Not Turn Steady Blue or Blinking Blue ............29 6.2.7 No Wireless Signal Searched ..................29 7 Appendix ............................30 7.1 Connectors and Media ......................30 7.2 Cabling Recommendations...................... 32 7.3 Optical Modules and Specifications ..................35 7.4 DC Connector Specifications ....................

  • Page 8: Product Introduction

    The RG-AP680-CD(V3) access point provides a combined data rate of 2.975 Gbps, with up to 575 Mbps in the 2.4 GHz band and 2.4 Gbps in the 5 GHz band. The RG-AP680-CD(V3) access offers one 2.5 GE SFP port and one 1GE copper port.
  • Page 9 Hardware Installation and Reference Guide Product Introduction Figure 1-2 Top View Figure 1-3 Side View...

  • Page 10: Package Contents

    Hardware Installation and Reference Guide Product Introduction Table 1-1 Port Description Item Description The console port is used to manage devices. Console/Reset The reset button is used to restart the access point or restore the access point to factory settings. DC connector Connected to the DC power supply Uplink service port for data transmission, compliant with the...

  • Page 11: Technical Specifications

    Dimensions and Weight Table 1-3 Dimensions and Weight Dimensions and RG-AP680-CD(V3) Weight Dimensions (W × D × H) 251 mm × 168 mm × 64 mm (9.88 in. x 6.61 in. x 2.52 in.) Access point: 1.5 kg (3.31 lbs.) Weight Mounting plate: 0.2 kg (0.44 lbs.)

  • Page 12: Port Specifications

    Hardware Installation and Reference Guide Product Introduction RF Specifications RG-AP680-CD(V3) Built-in smart antenna Antenna Type 2.4 GHz: horizontal lobe angle of 60 degrees and vertical lobe angle of 30 degrees 5 GHz: horizontal lobe angle of 60 degrees and vertical lobe angle of 30 degrees 2.4 GHz: 9 dBi...

  • Page 13: Power Supply And Consumption

    Three RSSI LEDs Button One reset button 1.4.4 Power Supply and Consumption Table 1-6 Power Supply and Consumption Power Supply RG-AP680-CD(V3) Consumption 1. DC power supply (48 V/0.35 Power Type 2. PoE/PoE+ (IEEE 802.3af/at-compliant) Maximum Power 12.95 W Consumption Caution ...

  • Page 14: Led And Button

    Hardware Installation and Reference Guide Product Introduction Environment RG-AP680-CD(V3) Reliability IP Rating IP68 Anti-corrosion Rating 24d salt spray test Safety Regulations GB 4943.1, IEC 60950-1, IEC 60825-1 EMC Regulations EN 300386, GB/T 19286, GB/T 17618 LED and Button Note The LED description applies to both fit and fat modes unless otherwise specified.

  • Page 15: Optical Module

    Hardware Installation and Reference Guide Product Introduction Table 1-9 Reset button Button Operation Result Press the button for less Reboot the device. than 2s Reset button Press and hold the button Restore to factory settings. for longer than 5s Table 1-10 Bridge LED No.
  • Page 16 Hardware Installation and Reference Guide Product Introduction Table 1-12 Rate Negotiation for an Electrical Port on the Peer Device Negotiated Rate Supported by the Port on the Peer Device Optical Port Rate of O/E Conversion 1 Gbps/10 1 Gbps/2.5 Gbps/10 Access Module Rate 1 Gbps...

  • Page 17: Preparing For Installation

    Hardware Installation and Reference Guide Preparing for Installation Preparing for Installation Safety Precautions Note  To avoid personal injury and device damage, carefully read the safety precautions before you install the device.  The following safety precautions may not cover all possible dangers. 2.1.1 General Safety Precautions ...

  • Page 18: Storage Security

    Hardware Installation and Reference Guide Preparing for Installation of accidents.  Check the access point carefully for confirmation before shutting down the power supply.  Do not place the device in a damp/wet location. Do not let any liquid enter the chassis. ...

  • Page 19: Cleanness Requirements

    Hardware Installation and Reference Guide Preparing for Installation Note The ambient temperature and humidity of the device are measured at the point that is 1.5 m (59.06 in.) above the floor and 0.4 m (15.75 in.) before the device when there is no protective plate in front or at the back of the device.

  • Page 20: Anti-Interference Requirements

    Take electromagnetic shielding measures when necessary. 2.2.8 Lightning Protection Requirements The RG-AP680-CD(V3) can guard against lightning strikes. As an electric device, too strong lightning strikes may still damage the device. Take the following lightning protection measures:  Ensure that the neutral point of the AC power socket is in good contact with the ground.

  • Page 21: Other Requirements

    Anti-static wrist strap, stripping plier, crimping plier, and wire cutter Meters Multimeter and bit error rate tester (BERT) Other tools PC, display, and keyboard Note The RG-AP680-CD(V3) is not shipped with a tool kit. You need to prepare a tool kit by yourself.

  • Page 22: Installation

    Hardware Installation and Reference Guide Installation Installation The RG-AP680-CD(V3) must be installed at a fixed position. Caution Before installing the device, make sure that you have carefully read the requirements described in Chapter 2. Installation Procedure The installation steps are shown in the following figure.

  • Page 23: Before You Begin

    Hardware Installation and Reference Guide Installation Before You Begin Carefully plan and arrange the installation location, networking mode, power supply, and cabling before installing the device. Confirm the following requirements before installation:  The installation location provides sufficient space for heat dissipation. ...

  • Page 24: Installing The Access Point

    Installing the Access Point 3.4.1 Mounting the Access Point on a Wall (1) Secure the mounting bracket to the bottom of the RG-AP680-CD(V3) access point using four M5 screws. Figure 3-3 Securing Mounting Bracket to Access Point (2) Install the mounting plate on a wall using four M6 expansion anchors.

  • Page 25: Mounting The Access Point On A Pole

    (3) Secure the mounting bracket to the mounting plate using two M6 screws. Figure 3-5 Securing Mounting Bracket to Mounting Plate 3.4.2 Mounting the Access Point on a Pole (1) Secure the mounting bracket to the bottom of the RG-AP680-CD(V3) access point using four M5 screws.
  • Page 26 Hardware Installation and Reference Guide Installation Figure 3-6 Securing Mounting Bracket to Access Point (2) Attach the mounting plate to a pole by threading two hose clamps through openings of the mounting plate. Figure 3-7 Attaching Mounting Plate to Pole (3) Secure the mounting bracket to the mounting plate using two M6 screws.

  • Page 27: Removing The Access Point

    Hardware Installation and Reference Guide Installation Figure 3-8 Securing Mounting Bracket to Mounting Plate Caution  Use matching screws for the screw holes, and tighten the structural parts in different installation links.  Tighten all fastening screws. If any screw is not installed, the device may vibrate violently, shift, or fall down. ...

  • Page 28: Connecting Cables

    Hardware Installation and Reference Guide Installation Connecting Cables 3.6.1 Connecting the Grounding Cable The grounding cable needs to be made on site. Connect one end of the grounding cable delivered with the device to the ground hole of the device through an OT terminal and the other end to the ground through another OT terminal.

  • Page 29: Connecting The Optical Fiber

    Hardware Installation and Reference Guide Installation Figure 3-11 Threading Network Cable Through Cable Gland Assembly (3) After threading the network cable through the cable gland assembly, install an RJ-45 connector on the unterminated end of the Ethernet cable. Wrap waterproof materials around the network cable between B (split gasket) and C (grommet).

  • Page 30: Connecting The Power Cable

    Hardware Installation and Reference Guide Installation Figure 3-13 Threading Optical Fiber Through Cable Gland Assembly (3) Plug the optical fiber into the optical transceiver and tighten A (adapter base). (4) Slide B (split gasket) and C (grommet) along the cable, pressing firmly to seat B (gasket) completely into C (grommet).

  • Page 31: Bundling Cables

    Hardware Installation and Reference Guide Installation Bundling Cables 3.7.1 Precautions  Bundle cables neatly to ensure aesthetics.  Bend twisted pairs naturally or to a large radius close to the connector.  Do not over tighten twisted pair bundle as it may reduce the cable life and performance. 3.7.2 Bundling Description After the cables are connected with the device through the waterproof plugs and power-on is normal, use a...

  • Page 32: Checking Cable Connections

    Hardware Installation and Reference Guide Installation 3.8.2 Checking Cable Connections  Verify that the twisted pair cable matches the port.  Verify that cables are properly bundled. 3.8.3 Checking the Power Supply  Verify that the power cord is properly connected and compliant with safety requirements. ...

  • Page 33: Commissioning

    Hardware Installation and Reference Guide Commissioning Commissioning Establishing the Configuration Environment Use a power adapter or PoE to power the access point. When setting up the environment, pay attention to the following:  Verify that the access point is properly connected to the power source. ...

  • Page 34: Monitoring And Maintenance

    If the access point works in the fat mode, you can log in to the access point remotely for maintenance.  If the access point works in the fit mode, you can use a wireless controller to centrally manage and maintain the access point. Hardware Maintenance If the hardware is faulty, please contact Ruijie technical support.

  • Page 35: Troubleshooting

    Check whether the LEDs are normal. Check whether cables are properly connected with ports. Contact Ruijie technical support to check whether hardware faults exist. Common Troubleshooting Procedures 6.2.1 Ethernet Port Is Not Working After the Ethernet Cable Is Plugged In Verify that the device at the other end of the Ethernet cable is working properly.

  • Page 36: Led Is Steady Green

    Hardware Installation and Reference Guide Troubleshooting 6.2.4 LED Is Steady Green The device performs initialization after power-on. During this period, the LED keeps steady green and does not turn normal blue until the initialization is completed. Note: If the steady green persists for an hour, the device initialization fails and the device is faulty.

  • Page 37: Appendix

    Hardware Installation and Reference Guide Appendix Appendix Connectors and Media  1000BASE-T/100BASE-TX/10BASE-T port The 1000BASE-T/100BASE-TX/10BASE-T port supports three kinds of adaptive speeds and supports the automatic MDI/MDIX crossover function under at these three kinds of speeds. Compliant with IEEE 802.3ab, the 1000BASE-T port requires 100-ohm Category 5/5e UTP or STP with a maximum distance of 100 meters.
  • Page 38 Hardware Installation and Reference Guide Appendix Socket Plug Output Transmit Data- Input Receive Data- 4, 5, 7, 8 Not Used Not Used The following figure shows wiring of straight-through and crossover cables for 100BASE-TX/10BASE-T. Figure 7-3 100BASE-TX/10BASE-T Twisted Pair Connections...

  • Page 39: Cabling Recommendations

    Hardware Installation and Reference Guide Appendix Cabling Recommendations During installation, route cable bundles upward or downward along the sides of the rack depending on the actual situation in the equipment room. All cable connectors should be placed at the bottom of the cabinet rather than be exposed outside of the cabinet.
  • Page 40 Hardware Installation and Reference Guide Appendix ○ The cable management brackets and cabling troughs inside and outside the cabinet should be smooth without sharp corners. ○ The metal hole traversed by cables should have a smooth and fully rounding surface or an insulated lining.
  • Page 41 Hardware Installation and Reference Guide Appendix ○ The power cables connecting moving parts such as door grounding wires should be reserved with some access after being assembled to avoid suffering tension or stress. When a moving part reaches the installation position, the remaining cable part should not touch heat sources, sharp corners, or sharp edges.

  • Page 42: Optical Modules And Specifications

    Hardware Installation and Reference Guide Appendix Optical Modules and Specifications We provide appropriate optical modules according to the port types. You can select the module to suit your specific needs. The optical module types and corresponding specifications are provided for reference. Table 7-1 SFP Modules and Specifications Intensity of...

  • Page 43: Dc Connector Specifications

    Hardware Installation and Reference Guide Appendix DC Connector Specifications  Input voltage: 48 V DC; rated current: 0.35 A Table 7-4 DC Connector Specifications Inner Diameter Outer Diameter Depth Polarity 2.0 mm (0.08 in.) 6.3 mm (0.25 in.) 9.8 mm (0.39 in.) Inner Positive, Outer Negative Figure 7-8...
