Hardware Installation and Reference Guide
No.
4
5
6
7
8
9
1.4

Technical Specifications

1.4.1

Dimensions and Weight

Table 1-5 Dimensions and Weight
Dimensions and
Weight
Dimensions (W × D ×
H)
Weight
Installation Method
Color
Anti-Theft Lock
Mounting Bracket
Dimensions (W × D ×
H)
Item
Phillips pan head screws M4 x 20
External optical module
Wire saddle
Quick start guide
Warranty card and list of hazardous
substances
Package Contents
RG-MAP852-SF-M
86 mm ×160 mm × 32.5 mm
AP: 0.30 kg (0.70 lbs)
Mounting bracket: 0.05 kg (0.11 lbs)
Embedding in an 86-type panel
White
Security screw
160.8 mm × 86 mm × 8 mm
(3.39 in. x 6.30 in. x 1.28 in.)
(6.33 in. x 3.39 in. x 0.31 in.)
7
Product Introduction
Quantity
2
1
3
1
1
1
