1 Product Overview

The RG-AP680-I is a wireless access point (AP) designed by Ruijie for next-generation high-speed wireless LANs.
Adhering to the latest 802.11ax standard, the AP delivers an access rate of up to 2400 Mbps+1150 Mbps and 867 Mbps
when using the wireless bridge. It features security, radio frequency (RF) control, mobile access, Quality of Service (QoS),
and seamless roaming. In addition, it can be managed by RG-WS series wireless access controllers (ACs) to implement
wireless data forwarding, security, and access control.
The IP68 design adapts to inclement outdoor environments such as the cold and humidity. This substantially simplifies
installation and maintenance. The RG-AP680-I offers flexible antenna switching and full coverage for various outdoor
situations. Moreover, multi-hop and point-to-multi-points bridging enhances the deployment. The AP fed by IEEE
802.3at-compliant PoE accommodates various monitors and receives real-time monitoring information. It is perfectly
suited for such sites as campuses, city blocks, and plazas.

1.1 Technical Specifications

Table 1-1 RG-AP680-I Technical Specifications
Model
Dimensions
(L×W×H)
RF design
Maximum Transmit
Rate
Operating
Frequency
Maximum Transmit
Power
Antenna Type
Antenna Gain
BLE
RG-AP680-I
Φ310mm × 120mm
three radios. the three RF port can switch between 2.4 GHz and 5 GHz bands.
Radio1: 2.4 GHz, 4 streams: 4x4
Radio2: 5 GHz, 4 streams: 4x4
Radio3:
2.4 GHz, 1 streams: 1x1
5 GHz, 2 streams: 2x2
Radio1：2.4GHz，1.150Gbps
Radio2：5GHz，2.400Gbps
Radio3：2.4GHz/5GHz，150Mbps/867Mbps
Maximum access rate of the AP
2.4GHz+5GHz+5GHz：4.417Gbps
2.4GHz+5GHz+2.4GHz：3.7Gbps
802.11b/g/n/ax: 2.4 - 2.483GHz
802.11a/n/ac/ax: 5.47 - 5.725GHz，5.725 - 5.850GHz
802.11a/n/ac: 5.150 - 5.350GHz
(Country-Specific)
23+6 dBm (Adjustable, country-specific)
Internal smart antenna, supporting internal and external antenna switchover
2.4 GHz: 6dBi
5 GHz: 6dBi
Support
Support Bluetooth Console
