Hardware Installation and Reference Guide
No. Item
9
Waterproof connector for the
fiber-optic cable
10
Metal hook
11 Ground cable
12 Product warranty manual
13
Dust cap for ports
14 User Manual
1.4

Technical Specifications

1.4.1

Dimensions and Weight

Table 1-4 Dimensions and Weight
Dimensions and
Weight
Dimensions (W × D
× H)
Weight
Installation
Quantity
1
2
1
1
4
1
RG-AP680-IO
300 mm × 300 mm × 94 mm (11.81 in. x 11.81 in. x 3.70 in.)
Main unit: 4.0 kg (8.82 lbs)
Mounting bracket: 1.5 kg (3.31 lbs)
Wall-mounted or pole-mounted
5
Product Introduction
Remarks
cables with a diameter of 6.6 to
8.6 mm.
The rubber plug has two holes
and adapts to LC-LC fiber-optic
cables with a diameter of 2.5 to
3.5 mm.
Adapts to poles with a diameter
of 80 to 140 mm
The dust caps are pre-installed on
the AP.
