Hardware Installation and Reference Guide
Technical Specifications
1.4
Dimensions and Weight
1.4.1
Dimensions and Weight
Dimensions (W × D × H)
Rack Height
Installation Mode
Port Specifications
1.4.2
Port
Fixed Service Ports
Fixed Management Ports
Status Indicator
RG-AM5528-SF
442 mm × 315 mm × 43.6 mm (17.40 in. x 12.40 in. x 1.72 in.)
1 U
Rack
RG-AM5528-SF
Uplink: 4 × 10G SFP+ ports. The four ports need to switch to
10G SFP+ mode or 1G SFP mode simultaneously and cannot
be independently set.
Downlink: 24 × 1G/2.5G SFP ports and 24 × PoE ports. Ports 1
to 20 support the PoE/PoE+ function, and each port supports
up to 30 W PoE power supply. Ports 21 to 24 support
PoE/PoE+/PoE++, and each port supports up to 90 W PoE
power supply.
The maximum PoE output power is 480 W.
1 × RJ45 console port
1 × 10/100/1000Base-T adaptive MGMT port
24 × PoE power supply status indicators
24 × 1000Base-X/2500Base-X SFP port status indicator
4 × SFP+ port indicators
1 × system indicator
One power LED
1 × MGMT indicator
5
