Operation guide | iSave 40
Instruction | Right and wrong - Hose assembly routing tips
WRONG
WRONG
To prevent hose collapse and flow restriction,
hose bend radii should be kept as large as
possible. Tight bends can also compromise
the hose reinforcement and cause premature
hose failure. Refer to hose specification table
on page 6 for minimum bend radii.
180R9239 | AQ299555093252en-001601 | iSave 40 | 09.2022
180R9434 | AN375455762639en-000201 | 07.2021
RIGHT
RIGHT
