Booster Pump (Vane Pump), Partslist - Danfoss iSave 40 Series Operation Manual

Operation guide | iSave 40
Pos. Qnt. Designation
101 1 Port flange
102 2 Bearing
103 1 Port plate - in
104 1 Sealing plate - in
105 1 Adapter for lifting eye
106 1 Stator
107 1 Rotor
108 8 Pin
109 8 Vane
110 1 Sealing plate - out
111 1 Port plate - out
112 1 Outlet flange
113 1 3" Victaulic connection
114 1 Flange for shaft seal
115 3 Bleed plug
120 1 Lifting eye
121 4 Pin, Ø10x30
122 1 Shaft seal
123 2 Pin, Ø4x9
130 2 O-ring, Ø126x3
131 2 O-ring, Ø89x3
132 4 O-ring, Ø192x4
133 1 O-ring, Ø93x3
133 2 O-ring, Ø93x3
134 1 O-ring, Ø9,2x2,6
135 2 O-ring, Ø65x3
136 3 O-ring, Ø11x2
140 18 Bolt, M10x35 / CS A4-80
141 4 Bolt, M10x20 / CS A4-80
142 4 Bolt, M8x20 / CS A4-80
143 19 Bolt, M10x65 / CS A4-80
Note: Danfoss reccommends always to use seals and screw kit for inspection and repair.
36
10.5.2

Booster pump (vane pump), partslist

Note: The parts listed are not sold seperately,
only in various kits.
Material
Super Duplex
PEEK
Super Duplex
PEEK
AISI 316
Super Duplex
Super Duplex
PEEK
Super Duplex / PEEK
PEEK
Super Duplex
Super Duplex
Super Duplex
Super Duplex
Super Duplex
AISI 316
AISI 303
Hastelloy C276 NBR
PEEK
NBR
NBR
NBR
NBR
NBR
NBR
NBR
NBR
AISI 316
AISI 316
AISI 316
AISI 316
180R9239 | AQ299555093252en-001601 | iSave 40 | 09.2022
Exploded view, see section 10.5.7.
180F4118 180F4119 180F4120
Port Port Sealing
plate, plate, plate,
out in out
x
x
x
x
x
180F4121 180F4122 180F4123
Sealing Vane kit Sealing
plate, kit
in
x
x
x
x x
x
x
x
x
x
x
x
x
x
x
x
x
