Operation guide | iSave 40

5.4 Temperature and corrosion

The chart below illustrates the corrosive
resistance of different types of stainless steel
related to NaCl concentration and temperature.
80 º
C
70
60
50
316L
40
30
20
100
160
In order to minimise the risk of crevice
corrosion, always flush the iSave accord-
ing to the specified start/stop procedure.

5.5 Dimensions and weights

For dimensions and weights please refer to
"Dimensional drawings", appendix 10.4.

5.6 Electric motor data

See " Application range" and "Operating and
Maintenance instructions, electric motor"
in appendix 10.9.
Special motor design can be used.
180R9239 | AQ299555093252en-001601 | iSave 40 | 09.2022
Depending on the NaCl concentration, the fluid
temperature must be between:
+2°C to +50°C (+35.6°F to 122°F).
Duplex
Super Duplex
1000 10 000
1600 16000
5.7
The figure below shows a section view of the
iSave.
The iSave consists of a rotating isobaric pressure
exchanger and a positive displacement pump,
also called booster pump. The rotation speed of
the pressure exchanger and the pump is exactly
the same, as they are driven by the same electric
motor.
100 000
160000

How does the iSave work?

CI -
ppm
NaCI
ppm
