Operation guide | iSave 40
38
10.5.5

iSave on foot, vertical, 180F7003 and 180F7005

Exploded view, see section 10.5.11.
Pos. Qnt. Designation
1 1 iSave 180F7011
2 1 Bell housing
3 1 Electric motor
4 2 Foot for base plate
5 1 Base plate
6 1 Coupling
7 4 Bolt, M12 x 25
8 4 Washer
9 1 Bolt, M12 x 30
10 4 Washer
10 4 Bolt, M16 x 40
11 4 Washer
13 1 Plug
Note: Danfoss reccommends always to use seals and screw kit for inspection and repair.
10.5.6

Tool kit

Qnt.
1
1
1
1
3
1
1
1
180R9239 | AQ299555093252en-001601 | iSave 40 | 09.2022
Material
Super Duplex
Aluminium
Aluminium or cast iron
AISI 316
Aluminium/polymer
AISI 316
AISI 316
AISI 316
AISI 316
AISI 316
AISI 316
Polymer
Designation
Press bush shaft seal
Bolt, M6 x 45
Nut, M6
Handle
Press bushes for valve plate
Allen key, 6 mm
Allen key, 8 mm
Fork wrench, 24 mm
180F7003 180F7005
180Z0246 180Z0643
Coupling kit Coupling kit
x x
180F4112
Tool kit
X
X
X
X
X
X
X
X
