Operation guide | iSave 40
Pos. Qnt. Designation
1 1 Adapter ring
2 1 Adapter flange
3 3 3" Victaulic connection
4 6 Bleed plug
5 1 Bearing
6 1 Port plate, seawater
7 2 Valve plate
8 1 Retainer
9 1 Cylinder barrel
10 1 Casing
11 1 Port plate, brine
12 1 Bearing
13 1 Outlet flange
20 1 Lifting eye
21 4 Pin, Ø10.5x20
22 2 Pin, Ø6x10
23 12 Springs
30 6 O-ring, Ø11x2
31 3 O-ring, Ø65x3
32 2 O-ring, Ø182x4
33 24 Back-up ring
34 24 O-ring, Ø28x2
35 1 O-ring, Ø9.19x2.62
36 1 O-ring, Ø30.2x3
40 12 Bolt, M10x20 / CS A4-109
41 12 Bolt, M8x60 / CS A4-109
42 12 Bolt, M8x20 / CS A4-109
Note: Danfoss reccommends always to use seals and screw kit for inspection and repair.

10.5 iSave parts list

This parts list provides an overview of the
content of various service sets for the iSave 40
as well as exploded views of the iSave, pressure
exchanger and booster pump.
Material
Polymer
Super Duplex
Super Duplex
Super Duplex
PEEK
Super Duplex / PEEK
Super Duplex
Super Duplex
Super Duplex
Duplex
Super Duplex / PEEK
PEEK
Super Duplex
AISI 316
Super Duplex
AISI 303
Hastelloy C276
NBR
NBR
NBR
PEEK
NBR
NBR
NBR
AISI 316
AISI 316
AISI 316
180R9239 | AQ299555093252en-001601 | iSave 40 | 09.2022
10.5.1

Pressure exchanger

Note: The parts listed are not sold seperately,
only in various kits
Exploded view, see section 10.5.8.
180F4114 180F4115
Valve plate Port plate,
brine
x
x
180F4116 180F4117
Port plate, Sealing kit
seawater
x
x
x
x
x
x
x
x
x
x
x
x
x
35
