4.3. Connect to Power Over Ethernet (PoE)

Before You Begin
IMPORTANT
Connecting the Bolt II to PoE and DC power simultaneously may result in a current loop that could
damage both the power sources and the Bolt II. Ensure to use only one of the power connections at
a time.
NOTE
Both shielded and unshielded Ethernet cables may be used.
Procedure
Figure 3. Connect to Power Over Ethernet (PoE)
Connect the Bolt II Ethernet port to Power Over Ethernet (PoE).
Page 10 of 68
Connect to Power Over Ethernet (PoE)
SCM-1202-209 Version 1.0
