Surface Mounting
5.
Screw the Bolt II lock nut into place and tighten it.
Tightening torque: 5 Nm ±10 %
IMPORTANT
To keep the Bolt II sealed against dirt and moisture, make sure the housing sealing ring is
properly seated in its groove before tightening the lock nut.
SCM-1202-209 Version 1.0
®
™
Anybus
Wireless Bolt II
Page 9 of 68
